Upper Dlvert.r Assembly
pin
C-13489
Open
Position
o
-
...••
-
_-'
Closed
Position
Item Part Number
Description
1
AE-23-800
Coil Assembly
2
C-13490
Bracket Assembly
3
B-13488
Solenoid Bracket Assy
4
01-8-508-S
Solenoid Bracket
5
10-303
Master Spring
6
A-13491
Drive Arm Assembly
7
C-13432
Gate Diverter
8
02-4241
Plunger Coil
9
10-389
Gate Mechanism Spring
10
01-9588
Drive Link
11
23-6577
Plug Bumper, 5/8" D.
12
10-320
Spring Extension
13
20-8712-43
"E" Ring, 7/16" Shaft
14
20-8712-25
"E" Ring, 1/4" Shaft
<_
15
20-8712-18
"E" Ring, 3/16" Shaft
16
4700-00073-00
Flatwasher, 9/32 x 1/2 x 21ga.
17
20-8716-2
Roll Pin, 3/32 x 5/8
18
20-8716-5
Roll Pin, 1/8 x 7/16
19
4008-01017-06
Mach. Screw, #8-32 x 3/8
20
4006-01003-06
Mach. Screw, #6-32 x 3/8
ROLLERGAMES 61
