Lower Metal Ramp
pin
C-13470
Top Metal Ramp
pin
C-13468
Upper Plastic Ramp
pin
R-13510
Item Part Number
Description
Hem Part Number
Description
1 A-13487
Switch Gate Assembly
15 31-1557-576-3 Ramp Decal
2 A-13669
Bracket Sw Gate Assembly 16 31-1557-576-4 Ramp Decal
3 B-13668
Ball Guide Ramp Assembly 17 31-1558-576-1 Ramp Decal
4 C-13337
Single Flashlamp Assembly 18 31-1558-576-2 Ramp Decal
5 C-13489
Upper Diverter Assembly
19 31-1558-576-3 Ramp Decal
6
C-13702
Playfield Plastic Assembly
20 31-1558-576-5 Ramp Decal
7 H-13548
Ramp Cable
21 4006-01003-08 Mach. Screw, 6-32 x 1/2
8 01-9601
Ramp Flap
22 4106-01004-06 Sh. Metal Screw, #6 x 3/8
9 03-8149-9
Mini Dome-Trans. Red
23 4106-01019-08
sn
Metal Screw, #6 x 1/2
10 03-8378
Plastic Ramp
24 4404-01119-00 Nut, 4-40 ESN
11 07-6688-22N Rivet, 5/16 x 7/32
25 4406-01119-00 Nut, 6-32 ESN
12 31-1006-576-1 Playfield Plastic
26 4700-00003-00 Flatwasher, 1/8 x 9/32 x 21ga.
13 31-1557-576-1 Ramp Decal
27 4700-00005-00 Flatwasher, 9/64 x 7/16 x 21ga.
14 31-1557-576-2 Ramp Decal
28 4700-00011-00 Flatwasher, 11/64 x 7/16 x gao
Item Part Number
1 C-13469
. a) 01-9562
b) 01-9564
c) 01-9563
2 01-9045
3 07-6688-16N
4 20-9284
5 07-6700
Description
Hem Part Number
Description
Ramp Welded Assembly
Ramp Floor
Ramp Bracket
Ramp Bracket
Ramp Flap
Rivet, 1/8" x 1/8"
Spade Bolt
Pop Rivet
1 01-9558
2 01-9559
3 01-9560
4 01-9561
Ramp Floor
Ramp Wall Outer
Ramp Wall Inner
Strap Mounting
._
ROLLERGAMES 60
