RAISING THE PLAYFIELD
&
CAUTION
This game uses ski assemblies to raise and lower the playfield. Be sure the back of the playfield
skis slide along the cabinet tracks until the feet hook into the loop at the end of the track.
Before Raising the Playfield:
Be sure there are no balls present in any of the ball-holding playfield devices (i.e. poppers).
Raising the playfield with balls present in these locations may cause them to come loose and
damage the playfield. Use the "Empty Balls Test" to remove all of the balls from these locations.
To Raise the Plavfield:
1. Open the coin door. Remove the front
molding and the playfield glass. Lift the
playfield by the metal bracket under the
bottom arch.
Rest it on the top of the
cabinet.
2. Close the coin door. Grasp the playfield on
the sides and pull it toward you along the
track slides. Rotate the front of the playfield
up and back toward the backbox.
To Lower the Plavfield
1. Rotate the front of the playfield down and
push it back, away from you, along the track
slides. Rest it on top of the cabinet. Open
the coin door.
2. Grasp the playfield by the metal bracket
under the bottom arch and lower it back into
the cabinet. Replace the playfield glass and
the front molding. Close and lock the coin
door.
SLIDE THE FEET
OF THE PLAYFlELD
ALONG THE TRACKS.
BE SURE THE FEET
OF THE PI.AYFlELD
HOOK INTO THE
LOOP ON THE TRACKS.
1-8
