19. Move the game into the desired location. Adjust the leg levelers so that the playfield pitch is the
recommended
6-1/2
degrees. This places the game in a FIXED position.
20. If a padlock is desired, install the security bar as shown below in Figure 13.
Slotted
Ho.spSto.ple Bracket
01-14086.1
Hasp Hnge Bro.cket
01-14085.1
Figure 13
21. Plug the game into a properly grounded outlet.
&
CAUTION
After assembly and installation at its site location, this game must be plugged into a properly
grounded outlet to prevent shock hazard, and to assure proper game operation. DO NOT use a
'cheater' plug to defeat the ground pin. DO NOT cut off the ground pin.
22. POWERING UP. With the coin door closed, plug the game in and switch it on. In normal operation
the game performs Start-up Tests. Once the Start-up tests have been successfully completed, the
game enters the Attract mode.
23. IMPORTANT: Fill out and return the registration card.
1-7
