GAME CONTROL LOCATIONS
Cabinet Switches
The ON/OFF SWITCH is on the bottom of the cabinet near the right front leg.
The START BUTTON is a push-button to the left of the coin door on the cabinet exterior. Press the Start
button to begin a game, or during the diagnostic mode, to ask for HELP.
Coin Door Buttons
The operator controls all game adjustments, obtains bookkeeping information, and diagnoses problems,
using only four push-button switches mounted on the inside of the coin door. The coin door buttons have
two modes of operation Normal Function and Test Function.
NORMAL FUNCTION
The SERVICE CREDITS button puts credits on the games that are not included in any of the game
audits.
The VOLUME UP
(+)
button raises the sound level of the game. Press and hold the button until the
desired level is reached.
The VOLUME DOWN (-) button lowers the sound level of the game. Press and hold the button until
the desired level is reached. See the Adjustment menu to tum the sound down all the way.
The **BEGIN TEST button starts the Menu System operation and changes the coin door buttons from
Normal Function to Test Function.
TEST FUNCTION
The ESCAPE button allows you to get out of a menu selection or retum to the Attract mode.
The UP
(+)
button allows you to cycle forward through the menu selections or adjustment choices.
The DOWN (-) button allows you to cycle backward through the menu selections or adjustment
choices.
The ENTER button allows you to get into a menu selection or lock in an adjustment choice.
COIN DOOR BunONS
_---_
SERVICE LOCK
20-10690
"LEVER
FRONT MOLDING
A-22997
FLIPPER BUTTON ASSEMBLY
A-22984
LAUNCH BUTTON
20-10692-1
ON/OFF SWITCH
5642-13935-00
(under cabinet)
The START BUTTON (p/n 20-9663-16)
is not shown on this drowing.
It is located below the servoce lock.
*The LEVER is part of the LOCK BRACKET ASSEMBLY (pin A-22996).
**
To reset the High Scores, press and hold the BEGINTEST button.
1-9
