POWER DRIVER BOARD CONTINUED ...
J115-1 Yellow-White, 6.8VAC from transformer secondary
J115-2 White-Brown, 6.8VAC from transformer secondary
J115-3 White-Brown, loop from J115-2
J115-4 White-Orange, 6.8VAC from transformer secondary
J115-5 White-Yellow, loop from J115-6
J115-6 White-Yellow, 6.8VAC from transformer secondary
J115-7 Orange, 6.8VAC from transformer secondary
J115-8 Orange, 6.8VAC loop from J115-7
J115-9 Key
J115-10 Green, 6.8VAC from transformer secondary
J115-11 Brown, 6.8VAC from transformer secondary
J115-12 Brown, 6.8VAC 100pfromJ115-11
J116-1 Key
J116-2 Gray-Yellow, +12VDC to coin door; J2-4
J116-3 Black, Ground to coin door; J2-5
J 116-4 Not Used
J117-1 Key
J117-2 Gray-Yellow, +12VDC to J606-7
J117-3 Black, Ground to J606-3
J117-4 Gray, +5VDC to J606-5
J118-1 Key
J118-2 Gray-Yellow, +12VDC to playfield
J118-3 Black, Ground
J11 8-4 Not Used
J119-1 White-Violet, 6.8VAC G.I. to coin door; J2-2
J119-2 Key
J119-3 Violet, Return G.I. to coin door; J2-1
J120-1 Brown, Return G.I. to playfield
J120-2 Orange, Return G.1. to playfield
J120-3 Yellow, Return G.I. to playfield
J120-4 Key
J120-5 Green, Return G.l. to playfield
J120-6 Violet, Return G.1.
t.c'
,-,Iayfield
J120-7 White-Brown, 6.8V';C to playfield
J120-8 White-Orange, 6.8VAC to playfield
J120-9 White-Yellow, 6.8VAC to playfield
J120-10 Whrte-Green, 6.8VAC to playfield
J120-11 White-Violet, 6.8VAC to playfield
J121-1 Brown, Return G.I. to insert
J 121-2 Orange, Retu rn G.I. to insert
J121-3 Yellow, Return G.1. to insert
J121-4 Key
J121-5 Green, Return G.1. to insert
J 121 -6 Not Used
J121-7 White-Brown, 6.8VAC to insert
J121-8 White-Orange, 6.8VAC to insert
J121-9 White-Yellow, 6.8VAC to insert
J121-10 White-Green, 6.8VAC to insert
J121-11 Not Used
J122-1 Blue-Brown, Sol 25 to playfield flashlamps
J122-2 Blue-Red, Sol 26 to playfield flash lamps
J122-3 Blue-Orange, Sol 27 to playfield flash lamps
J122-4 Not Used
J122-5 Not Used
J122-6 Not Used
J122-7 Key
J122-8 Not Used
J122-9 Not Used
J123 Not Used
J124-1 Blue-Brown, Sol 25 to insert flash lamps
J124-2 Blue-Red, Sol 26 to insert flash lamps
J124-3 Blue-Orange, Sol 27 to insert flashlamps
J124-4 Key
J124-5 Blue-Yellow, Sol 28 to insert flashlamps
J125-1 Black-Brown, Sol 17 to insert flashlamps
J125-2 Black-Red, Sol 18 to insert flashlamps
J125-3 Black-Orange, Sol 19 to insert flashlamps
J125-4 Key
J125-5 Black-Yellow, Sol 20 to insert flashlamps
J125-6 Blue-Green, Sol 21 to insert flash lamps
J125-7 Blue-Black, Sol 22 to insert flashlamps
J125-8 Blue-Violet, Sol 23 to insert flashlamps
J125-9 Not Used
J126-1 Black-Brown, Sol 17 to playfield flash lamps
J 126-2 Black-Red, Sol 18 to playfield flash lamps
J126-3 Black-Orange, Sol 19 to playfield flash lamps
J 126-4 Black-Yellow, Sol 20 to playfield flashlamps
J126-5 Blue-Green, Sol 21 to playfield flash lamps
J126-6 Blue-Black, Sol 22 to playfield flash lamps
J 126-7 Blue-Violet, Sol 23 to playfield flashlamps
J126-8 Blue-Gray, Sol 24 to playfield flashlamps
J126-9 Key
J126-10 Not Used
J126-11 Not Used
J126-12 Not Used
J126-13 Not Used
J127-1 Brown-Black, Sol 9 to playfield coil
J127-2 Key
J127-3 Brown-Red, Sol 10 to playfield coil
J 127 -4 Brown-Orange, Sol 11 to playfield coil
J127-5 Not Used
J127-6 Brown-Green, Sol 13 to playfield coil
J127-7 Not Used
J127-8 Brown-Violet, Sol15 to playfield coil
J127-9 Brown-Gray, Sol 16 to playfield coil
P,C, Board legend
J1 ·J6 Coin Door Interface Board
J1xx Power Driver Board
J2xx CPU Board
J5xx Audio Board
,)6xx Dol Malrix Controller Board
J9xx Fllptronic II Board
Judge Dredd 3-28
