POWER DRIVER BOARD
A-12697-3
J 101-1 Red, 9VAC from transformer secondary
J1 01-2 Red, 9VAC from transformer secondary
J1 01-3 Key
J 101-4 Blue-White, 13VAC from transformer secondary
J 101-5 Blue-White,
loop from J 101-4
J 101-6 Blue-White, 13VAC from transformer secondary
J 101-7 Blue-White, loop from J 101-6
J102-1 White-Red, loop from J102-2
J 102-2 White-Red, 16VAC from transformer secondary
J1 02-3 White-Red, loop from J1 02-4
J 102-4 White-Red, 16VAC from transformer secondary
J102-5 Black-Yellow, loopfromJ102-6
J102-6 Black-Yellow, 16VAC from transformer secondary
J102-7 Key
J102-8 Black-Yellow, loop from J102-9
J102-9 Black- Yellow, 16VAC from transformer secondary
J103 Not Used
J104 Not Used
J105-1 White-Blue, 50VAC to J901-1
J105-2 White-Blue, 50VAC to J901-3
J105-3 Key
J 105-4 Not Used
J105-5 Not Used
J 106-1 Not Used
J106-2 Not Used
J 106-3 Not Used
J106-4 Key
J106-5 Red-White, +20V to insert flash lamps
J107-1 Not Used
J107-2 Violet-Orange, 50V to playfield coils
J1 07-3 Violet-Yellow, 50V to playfield coils
J107-4 Key
J107-5 Not Used
J107-6 Red-White, +20V to playfield flashlamps
J108 Not Used
J109 Not Used
J110 Not Used
J111 Not Used
J112-1 White-Green, 9.8VAC from transformer secondary
J112-2 White-Green, loop from J112-1
J112-3 White-Green, 9.8VAC from transformer secondary
J112-4Key
J112-5 White-Green, loop from J112-3
B 1·········1
1·······1
1 4 1
9
1
7
Jl03
Jl02
Jl0l
rn '"
r-,
o
~
,_
rn
"g
~
,
_
rn
a>
o
~~
,
.
_
[l) '" ~
~
_,
Jl13
Jl14
J115
~
1············1
7
c.=:.::J
1 12
1
""Il:r ~[]_
~m~:!~m: :
••••••
1:1
,....
II
...-
a
.••..•
II
...,
II
..,....,
II
-e
~I:::::::::::::::::I~
J 113 Ribbon Cable, Data to/from J211
J114-1 Gray/Green, +12VDCtoJ210-7
J 114-2 Not Used
J 114-3 Gray, +5VDC to J21 0-5; J502-3
J114-4 Not Used
J114-5 Not Used
J114-6 Key
J 114-7 Black, Ground to J21 0-1 ; J502-4; J904-4
P.C. Board Legend
J1-J6 Coin Door Interface Board
J1xx Power Driver Board
J2xx CPU Board
J5xx Audio Board
J6xx Dot Matrix Controller Board
J9xx Fliptron ic " Board
Judge Dredd 3-27
