POWER DRIVER BOARD CONTINUED ...
J128 Not Used
J137-1 Not Used
J137-2 Not Used
J137-3 Yellow-Orange, Col 3 to cabinet lamp
J137-4 Not Used
J137-5 Not Used
J137-6 Not Used
J137-7 Not Used
J137-8 Key
J137-9 Yellow-Gray, Col 8 to cabinet lamp
J129 Not Used
J130-1 Violet-Brown, Sol 1 to playfield magnet
J130-2 Violet-Red, Sol 2 to playfield coil
J130-3 Key
J130-4 Violet-Orange, Sol 3 to playfield coil
J130-5 Violet-Yellow, Sol4 to playfield motor
J130-6 Violet-Green, Sol 5 to playfield coil
J130-7 Violet-Blue, Sol 6 to playfield motor
J130-8 Violet-Black, Sol 7 to playfield coil
J130-9 Violet-Gray, Sol 8 to playfield coil
J131 Not Used
J138-1 Yellow-Brown, Col 1 to playfield lamps
J138-2 Yellow-Red, Col 2 to playfield lamps
J138-3 Yellow-Orange, Col 3 to playfield lamps
J 138-4 Yellow-Black, Col 4 to playfield lamps
J138-5 Yellow-Green, Col 5 to playfield lamps
J 138-6 Yellow-Blue, Col 6 to playfield lamps
J138-7 Yellow-Violet, Col 7 to playfield lamps
J138-8 Key
J138-9 Yellow-Gray. Col 8 to playfield lamps
J132 Not Used
J 133 Not Used
J134-1 Red-Brown, Row1 to playfield lamps
J134-2 Red-Black, Row2 to playfield lamps
J134-3 Key
J134-4 Red-Orange, Row3 to playfield lamps
J134-5 Red-Yellow, Row4 to playfield lamps
J134-6 Red-Green, Row5 to playfield lamps
J134-7 Red-Blue, Row6 to playfield lamps
J134-8 Red-Violet, Row7 to playfield lamps
J134-9 Red-Gray, Row 8 to playfield lamps
J 135-1 Not Used
J 135-2 Not Used
J135-3 Key
J 135-4 Not Used
J 135-5 Not Used
J 135-6 Not Used
J 135-7 Not Used
J 135-8 Red-Violet, Row 7 to cabinet lamp
J135-9 Red-Gray, Row 8 to cabinet lamp
J136 Not Used
p.c.
Board Legend
J1·J6 Coin Door Interface Board
J1xx Power Driver Board
J2xx CPU Board
J5xx Audio Board
J6xx Dot Matrix Controller Board
J9xx Fliptronic II Board
Judge Dredd 3-29
