COIN DOOR INTERFACE BOARD
A-14689
ooooooooJ600000woo
1
18
o
o
o
<.OW
""'0
o
o
o
o
o
o
o
~ 0
o
o
w
o
J1-1 Green-Brown, switch column 1 from J212-1
J1-2 Red-Gray, lamp row 8 from J134-9
J1-3 White-Yellow, switch row 4 from J212-8
J1-4 White-Orange, switch row 3 from J212-7
J1-5 White-Red, switch row 2 from J212-6
J1-6 White-Brown, switch row 1 from J212-4
J1-7 Green-Red, switch column 2 from J212-2
J1-8 Orange-Gray, dedicated switch row 8 from J205-9
J1-9 Orange-Violet, dedicated switch row 7 from J205-8
J1-10 Orange- Blue, dedicated switch row 6 from J205-7
J1-11 Orange-Green,
dedicated switch row 5 from J205-6
J1-12 Orange-Biack, dedicated switch row 3 from J205-3
J1-13 Orange-Red, dedicated switch row 2 from J205-2
J1-14 Orange-Brown,
dedicated switch row 1 from J205-1
J1-15 Black, Ground from J20S-10
J1-16Key
J 1-17 Orange- Yellow, dedicated switch row 4 from J205-4
J1-18 Orange-White, switch enable from J205-12
J2-1 Violet, G.I. return from J 119-3
J2-2 White-Violet, G.I. 6.8VAC from J119-1
J2-3 Key
J2-4 Gray-Yellow, +12V from J116-2
J2-5 Black, Ground from J116-3
J2-6 Not Used
J2-7 Not Used
J2-8 Not Used
J3-1 Violet, G.I. return to coin door
J3-2 White-Violet, G.I. 6.8VAC to coin door
J3-3 Black, Ground to coin door
J3-4 Orange-Brown,
dedicated switch row 1 to coin door
J3-5 Orange-Red, dedicated switch row 2 to coin door
J3-6 Orange-Black, dedicated switch row 3 to coin door
J3-7 Orange-Green,
dedicated switch row 4 to coin door
J3-8 Orange-Blue, dedicated switch row 6 to coin door
J3-9 Orange-Violet, dedicated switch row 7 to coin door
J3-10 Key
J3-11 Orange-Gray, dedicated switch row 8 to coin door
J3-12 Green-Red, switch column 8 to coin door
J3-13 White-Brown, switch row 1 to coin door
Judge Dredd 3-26
J4 Not Used
J5 Not Used
J6-1 White-Red, switch row 2 to cabinet
J6-2 White-Orange, switch row 3 to cabinet
J6-3 White-Yellow, switch row 4 to cabinet
J6-4 Red-Gray, lamp row 8 to cabinet
J6-5 Key
J6-6 Green-Red, switch column 2 to cabinet
J6-7 Green-Brown, switch column 1 to cabinet
J6-8 Green-Brown, switch column 1 to cabinet
p,C,
Board Legend
J1-J6 Coin Door Interface Board
Jtxx Power Driver Board
J2xx CPU Board
J5xx Audio Board
J6xx Dot Matrix Controller Board
J9xx FI"tronic II Board
