A-16032-1
3-Bank Drop Target Assembly
Item Part Number
Description
Item Part Number
Description
1 A-17045
3-Bank Bracket & Stud Assy.
12 20-8712-18
"E"-Ring,
3116"
Shaft
2 A-11397
Stop Bracket Assembly
13 23-6626
Rubber Grommet
3 4408-01119-00 Nut #8 ESN
14 A-13609
3-Bank Opto Assembly
4 AE-26-1200
Coil Assembly
15 20-8712-25
"E"-Ring, 1/4" Shaft
5 03-7066-4
Coil Tubing, 2.093" Lg.
16 10-364
Spring, Retractor
6 02-3972-1
Plunger
17 4700-00016-00 Flatwasher, 3/16x7/16x17ga.
7 01-8413-1
Bracket Coil Mounting Assy.
18 03-8334-3
Target Stop, 3-15/16"
8 4010-01025-14 Mach. Screw, #10-32 x 7/8"
19 4004-01005-04 Mach. Screw, 4-40 x 1/4"
9 03-8749-1
Plain Target, Black
20 01-11769
Reset Plate
10 4700-00072-00 Flat Washer, 17/64x1/2x21ga.
21 4410-01132-00 Nut#10 ESNA
11 10-392
Spring, Extension
22 23-6622
Foam Tape, Double Sided
~
2-20
