Item Part No.
1 01-7567
2 03-7479
3 01-6450-3
4 B-8451
a) 4104-01001-04
b) 01-7037
c) 03-7478
d) 10-364
e) 4104-01001-04
5 4006-01003-15
6 01-7036
7 B-9354
a) 4006-01003-03
b) 01-7517
3-Bank Drop Target Assembly
pin
0-9355
Description
Item Part No.
Description
Drop Target Frame
7c) 01-7495
Switch Bracket
Drop Target Guide
d) 17-1042
Drop Target Switch
Target Retaining Bar
e) 4004-01003-10 Mach. Screw, 4-40 x
5/8,
Drop Target Assembly
P-PH-S
Sheet Metal Screw, #4 x 1/4,
8
4410-01132-00 Nut, 10-32 ESN
P-PH-A
9
4006-01017-04 Mach. Screw, 6-32 x
1/4
Target Backup Blade
10 02-3972
Drop Target Plunger
Drop Target
11 4700-00023-00 Washer,
13/16
o.d. x
5/8
i.d.,
Target Retractor Spring
16 gao
Sheet Metal Screw, #4 x
1/4,
12 AE-23-800-04 Coil Assembly
P-PH-A
13 03·7066-4
Coil Sleeve
Mach. Screw, 6-32 x
15/16,
14 01-6451-3A
Coil Support Angle
P-PH-S
15 4006-01017-04 Mach. Screw, 6-32 x
1/4,
Reset Plate
P-RH-S
Switch & Bracket Assembly
16 A-8037
Coil Stop Assembly
Mach. Screw, 6-32 x
3/16,
17 4106-01001-07 Sheet Metal Screw, #6 x
7/16,
P-PH-S
P-PH-ST
Switch Mounting Bracket
GRAND LIZARD 41
