A-14595
Island Mechanism Assembly
ftr
1
Item Part Number
Description
Item Part Number
Descrliptlon
~
1
A-14591
Island Mech. Bracket Assy.
b)
01-10207
Centering Ring Plate
2
A-14593-1
Motor Terminal Assembly
c)
41 06-01 043-05
#6 x 5/16 PH-FL T-B (4)
3
4006-01027 -06
MS #6-32 x 3/8 PH-R (2)
d)
4106-01033-08
#6 x 1/2 PH-TRS-AB (6)
4
4406-01128-00
Hex Nut #6-32 Keps (2)
e)
31-1 A-20003-1
Screened Plastic Cover
5
A-14534-1
PCB Opto Assembly
f)
31-2-20003-1
Decals
6
03-8338-1
Spacer #8 (2)
thru 31-2-20003-10
7
4008-01015-12B
TT #8-32 x 3/4 PH-P (2)
9
03-8590
FW .505 x .750 x .062
8
A-14513
5-Path Island Assembly
10 4008-01 076-06
SS #8-32 x 3/8
a)
03-8549
Plastic 5-Path Island
11 16-9213
Motor Rotation Decal
Note: To remove Island Mech. Bracket Assembly, remove set screw, Item 10.
'~
I
____--@
1
80
