Island Lock Mechanism Assembly
Item Part Number
Description
1.
01-10206
Isle Lock Mach. Bracket
2.
20-8790
Nyliner 1/4 i.d.
3.
02-4541
Locking Pin
4.
441 0-01129-00
Hex Nut 1-32 Sems
5.
01-10224
Switch Limit Actuator Brkt.
6.
02-4302
Threaded Plunger Shaft
7.
10-399
Compression Spring 2-9/16
8.
01-10225
Coil Support Bracket
9.
4106-01012-04
rr
#6-32x1/4 PH-poST (2)
10.
A-~4701
Coil Assembly
11.
03-7066
Coil Tubing
12.
A-1'0821
Coil Stop Bracket Assembly
13.
4010-01008-06
LMS #10-32x3/8 PH-poST (2)
14.
4701-00004-00
Lock Washer #10 Split (2)
15.
5647-12073-08
Mini Micro Switch
16.
01-8600
Switch Insulator
17.
5070-09054-00
Diode 1N4004 1.0A
18.
4002-01105-07
MS #2-56x7/16 PH-poST (2)
19.
01-8240
Switch Nut Plate 2-56
