Item Part Number
Description
Hem Part Number
Description
1.
A-11137
Lift Crank Assembly
15.
03-7066
Tubing, Coil
2:
4406-01119-00
Nut, 6-32 ESN
16.
4008-01021-07
Mach. Screw, 8-32 x
7/1
3.
A-8050
Plunger Assembly, 2-1/4"
17.
4701-00003-00
Lockwasher, #8 Split
4.
4700-00073-00
Flatwasher,9!32x1I2x21ga.
18.
4700-00089-00
Flatwasher,11/64x7/16x1
5.
12-6227
Hairpin Clip
19.
B-11302-1
Lift Mech Bracket Assy
6.
10-128
Spring
20.
A-6892
Frame & Eyelet Assy
7:
01-8-508-S
Coil Retaining Bracket
21.
SM1-26-600
Coil Assembly
8:
4006-01017 -06 Mach. Screw, 6·32 x 3/8
22.
A-11139
Armature Assembly
9:
AE-26-1200
Coil Assembly
a)
A-8936
Armature Sub-Assembly
10:
B-7572-1
Bracket & Stop Assembly
b)
01-8390
Lift Crank Lock
11.
4004-01003-10
Mach. Screw,
4
·40 x
5/8
c)
4006-01003-03
Mach. Screw, 6-32 x
3/1
12.
5070-06258-00
Diode, 1N4001. 1.0A.
23.
10-363
Extension Spring
13.
A-7438-1
Terminal Strip Assembly
24.
12-6227
Hairpin Clip
14.
5647-12001-00
Microswitch
• Part of Coil
&
Bracket Assembly, B-9362-L-2.
GILLIGAN'S ISLAND 2-24
8-11304-3 Ramp Lifting Mechanism
w/Coil & Bracket Assembly (B-9362-L-2)
