B-9361-R-5 Ball Eject Assembly
Item Part Number
Description
1.
A-6949-R
Spring Plate Assembly
2.
A-8268
Mounting Bracket Assembly
3.
A-7471-R
Eject Cam Assembly
4.
A-8050-1
a)
02-3407-2
Coil Plunger Assy, 2-1/8"
b)
20-8716-5
Call Plunger, 2-1/8"
c)
03-8085
Roll Pin, 1/8 x 7/16
5.
10-320
Spring Eject (Red)
6.
12-6227
Hairpin Clip
7.
4700-00030-00 Flatwasher, 17/64 x112 x 15ga.
8.
4700-00103-00 Flatwasher, 17/64 x1/2 x 28ga.
Associated Parts
A-14735
B-7572-1
01-8-508-S
4006-01 017-06
4406-01119-00
AE-28-1500
03-7066
Coil & Bracket Assembly
Bracket & Stop Assembly
Coil Retaining Bracket
Mach. Screw, 6-32 x 3/8
Nut, 6-32' ESN
Coil Assembly
Coil Tubing
B-11873 Bottom Arch Kicker Assembly
Item Part Number
Description
5
1.
A-6306-2
Bell Armature Assembly
2.
AE-23-800
Coil Sub-Assembly
I'
3.
B-7409-2
Mounting Bracket Assy.
~
2
4.
01-8-508-T
Solenoid Bracket
5.
03-7067-5
Coil Tubing
6.
10-135
Solenoid Spring
7.
23-6420
Rubber Grommet
8.
4008-01017-05 Mach. Screw, 8-32 x 5/16"
