8all Trough Switches
(Viewed from underside of playfield to show locations)
8-10686-1
Item Part Number
Description
1.
B-11348
Ball Trough Switch Plate Assy.
a) A-5844-44
Switch Wire & Bracket Assy.
b) B-11349
Switch Mounting Plate Assembly
c)
5647 -099 57 -00 uswitch, Center & Left Ball
d)
4004-01060-08 Mach. Screw, 4-40 x 1/2
e) 4005-01005-02 Mach. Screw, 5-40 x 1/8
f)
5070-06258-00 Diode, 1N4004, 1.0A.
g)
5825-09373-00 Solder Lug-Flat, #4
h)
RM-21-03
Insulating Tubing, #10 x 1.75
2.
A-11680
Ball Trough Switch, Right
a) 5647-12693-08 Submin. Switch
b) 5070-09054-00 Diode, 1N4001, 1.0A.
3.
A-8645
Switch Wire & Bracket Assy.
Knocker Assembly
Item Part Number
Description
1.
A-5387
Coil Plunger Assembly
a)
02-2653
Coil Plunger
b)
03-6013
Bell Arm Ext.
2.
B-7409-2
Mtg. Bracket Assembly
3.
AE-23-800
Coil Sub-Assembly
4.
01-8-508-T
Coil Retaining Bracket
5.
23-6420
Rubber Grommet
6.
4008-01017-06
Mach. Screw, 8/32 x 3/8
7.
H-11835
Knocker Cable
8.
03-7067-5
Coil Tubing
GILLIGAN'SISLAND 2-20
