AWrox
Playfield
Pitch
Angle:
6 - 7
Degrees
Nlt
4422-01117-
II
II
II
I
I
-
I
I
'-J
V
08
l
""-
-
/
C-10843
leg
-7377
eg leveller
Shaft
Foot Pad
•
PINBALL GAME ASSEMBLY INSTRUCTIONS
1. Open the shipping container; remove all cartons, parts, and other items, and set them aside.
2. Place the cabinet on a support and attach rear legs using leg bolts . Leg levellers and leg bolts
are provided among the parts in the cash box.
3. Attach the front legs (after installing leg levellers), using leg bolts. See Figure 3 for details.
•
Detail Vlew-
Leg Leveller
Figure 3. Pinball Assembly, Playfield Pitch Angle, and Leg Leveller Details.
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are free to move
(not kinked or pinched). Be careful to avoid damaging wires at any stage of the assembly process.
5. Raise the hinged backbox upright and latch it into position. Unlock the baekbox, and remove the
backbox glass, storing it carefully to avoid scratches. Remove the shipping block holding the
Insert Board .Unlatch the Insert Board and open it; lift the Speaker/Display Panel and lay it on the
playfield glass . This allows access to the bolt holes used for securing the backbox upright. Install
the washer-head mounting bolts through the bottomholes of the backbox into the threaded fasteners
in the cabinet to secure the backbox. Remount the Speaker/Display Panel; close the Insert Board
and latch it in position. ReinstaU the backbox glass, and lock the backbex,
•
FAlLURE TO INSTALL
the backbox mount ing hardware properly can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect.
Always
lower the backbox
forward onto the playfield cabinet on a layer of protective material to prevent marring or damag e
and possible personal injury .
FUNBOUSE 1-5
