Figure 2. Pinball Game Controls Locations
•
•
FUNHOUSE GAME CONTROL LOCATIONS
Cabinet Switches
The On-Off switch is on the bottom of the cabinet near the right front leg.
The Start Button is a pushbutton to the left of the coin door on the cabinet exterior. Press the Start
button to begin a game, or during the diagnostic mode, to ask for HELP.
Coin DoorSwitcbes
The operator controls all game adjustments, obtain bookkeeping information, and diagnose
problems, using only four pushbutton switches mounted on the inside of the coin door. The Coin
Door Switches have two modes of operation Normal Function and Test Function.
Normal Function
The Service Credits switch puts credits on the game that are not included in the game audits.
The Volume Up switch raises the sound level of the game. Press and hold the button until the
desired level is reached.
The volume Down switch lowers the sound level of the game . Press and hold the button until the
desired level is reached.
The BelPn Testswitch starts the Menu System Operation and changes the Coin Door Switches from
Normal Function to Test Function.
Test Function
The Escape switch allowsyou to get out of a menu selection or to return to the Attract Mode.
•
The
llP
switch allows you to cycle forword through the menu selections or adjustment choices .
The
.I!2ml.
switch allows you to cyclebackward through the menu selections or adjustment choices .
The
Ent&.r
switch allows you to get into a menu selection or lock in an adjustment choice .
Coin Door Switches
1).12615
Front Molding Assy.
FUNBOUSEl-4
