Page 633 - BallyMidway GREY Parts Catalog 16-9562-A

Coin Door Assemblies - cont'd
(Foreign - cont'd)
09-S200O-XX
3-Slot Coin Door With Acceptor
(Entropy)
Coin Door & Country Item Part Number Description
09-62000-1, Germany 4 27-1026-3 Coin Entry Plate, Left
27-1026-5 Coin Entry Plate, Center
27-1026-7 Coin Entry Plate, Right
5 27-1041-5 Price Label, Left
27-1041-6 Price Label, Center
27-1041-7 Price Label, Right
16 27-1075 Actuator Wire, Left
17 27-1093 Actuator Wire, Center
18 27-1093 Actuator Wire, Right
19 16-8982-2 Caution Label, German
20 16-9271-02 Bar Code Label
21 09-8843 Coin Acceptor, left
22 09-8888 Coin Acceptor, Center
23 09-8922 Coin Acceptor, Right
09-62000-2, Austria 4 27-1026-3 Coin Entry Plate, Left
27-1026-5 Coin Entry Plate, Center
27-1026-5 Coin Entry Plate, Right
5 27-1041-23 Price Label, Left
27-1041-24 Price Label, Center
27-1041-24 Price Label, Right
16 27-1075 Actuator Wire, Left
17 27-1093 Actuator Wire, Center
18 27-1093 Actuator Wire, Right
19 Not used
20 16-9271-03 Bar Code Label
21 09-8858 Coin Acceptor, Left
22 09-8859 Coin Acceptor, Center
2.3 09-8859 Coin Acceptor, Right
09-62000-5, Switzerland 4 27-1026-3 Coin Entry Plate, Left
27-1026·5 Coin Entry Plate, Center
27-1026-9 Coin Entry Plate, Right
5 27-1041-13 Price Label, Left
27-1041-14 Price Label, Center
27-1041-15 Price Label, Right
16 27-1075 Actuator Wire, Left
17 27-1093 Actuator Wire, Center
18 27·1093 Actuator Wire, Right
19 Not used
20 16·9271·02 Bar Code Label
21 09·8831 Coin Acceptor, Left
22 09·8897 Coin Acceptor, Center
23 09·8926 Coin Acceptor, Right
-Continued-
8-25
