Rollover Wire Switch and Bracket Assemblies - cont'd
Quantity
WORLD CUP (50031) - cont'd
Part Number
Description
Per Game
5647-12693-32
A-17791
R. O. Switch Assembly
1
a) 01-12356
Mounting Bracket
b) 4002-01105-06
MS 2-56
x
318
P-PH-S (2)
c) 5070-09054-00
Diode 1N4004, 1.0A
(See INDIANAPOLIS 500)
d) 5647-12693-32
Mini Micro Switch
A-18973
R.O. Switch Assembly
1
(See INDIANAPOLIS 500)
Quantity
The SHADOW (50032)
Part Number
Description
Per Game
5647-12693-19
A-17813
R.O. Switch Assembly
6
(See INDIANAPOLIS 500)
(See INDIANAPOLIS 500)
A-17791
RO. Switch Assembly
1
(See WORLD CUP)
564 7-12693-32
(See INDIANAPOLIS 500)
5647-12073-33
A-19076
3-Switch Bracket Assembly
1
a) 01-13218
Mounting Bracket
b) 4002-01105-06
MS 2-56 x
318
P-PH-S (6)
c) 5070-09054-00
Diode 1N4004, 1.0A (3)
d) 5647-12693-32
Mini Micro Switch
e) 5647-12073-33
Mini Micro Switch
f) 5647-12073-34
Mini Micro Switch
g) H-19690
Cable Assembly
564 7-12073-34
Note: See pp. 4-25 to 4-27 for assembly drawings.
4-24b
