Pinball Cabinet Assemblies
(50036)
Item Part Number
Description
Item Part Number
Description
1 A-19514-2
Leg Assembly, Black(4)
11 20-9663-2
~Start" Button, Green
2 A-17540
Universal Power Interface Ass'y
12 A-19123
Front Molding Ass'y, Black
3 (See Sect. 8)
5-Ball Cashbox Assembly
13 A-17051-1
Coin Door Interface Board
4 A-17316
Opto Flipper Ass'y (2)
14 A-15361
Tilt Mechanism Assembly
5 A-16883-4
Flipper Button, Red (2)
15 20-6502-A
Plumb Bob
6 A-17730-2
Ball Shooter Ass'y w/Knob, Slack.
16 5555-12929-00
Speaker 6", 4Q, 25W
7 A-16773
Lever Guide Assembly
17
5610-13953-00
WPC Transformer
8 (See Sect. 8)
Coin Door Assembly
..
A-17195
Tilt Switch Assembly
9 (See Sect. 6)
Interlock Switch/Cable Ass'y
10 20-9663-18
"Extra Ball" Button
w/Sw,
Orange
"Mounted on Cabinet floor.
