Pinball Cabinet Assemblies
™
(S0032)
Item Part Number
Description
Item Part Number
Description
1 A-19514
Leg Assembly, Chrome (4)
12 20-9663-1
"Start" Button w/Switch
2 A-17540
Universal Power Interface Ass'y
13 0-12615
Front Molding Assembly
3 (See Sect. 8)
5-8all Cashbox Assembly
14 A-17051-1
Coin Door Interface Board
4 A-17316
Opto Flipper Assembly (2)
15 A-15361
Tilt Mechanism Assembly
5 A-16883-1
Flipper Button, Blue (2)
16 20-6502-A
Plumb Bob
6 A-16883-4
Flipper Button w/Spring, Red (2)
17 5610-13953-00
WPC Transformer
7 A-18536
Gun Assembly
18 5555-12929-00
Speaker 6", 40, 25W
8
A-16773-1
Lever Guide Assembly
.•
A-17195
Tilt Switch/Cable Assembly
9
(See Sect. 8)
Coin Door Assembly
10 (See Sect. 6)
Interlock Switch/Cable Ass'y
*Mounted on Cabinet floor.
11 20-9663-9
-Extra Ball" Button w/Switch
(jJafPLt
/MIDWAY
2-4c
