Page 79 - 1987_BALLY_ASPIRE

TOP PlAYFIElD ASSEMBLY W/PLASTICS - PARTS LIST, CONT'D.PART NO. AE94-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
15 AE94-00020- 000 RAMP ASSY.: RT. (INCLUDES FOLLOWING 5 ITEMS)
OE94-00110-000 RIGHT RAt1P
OE94-00128-00XF BRACKET: RAMP
OE94-00129-0000 RAMP TOP: SPRING
OE94-00131-00XF BRACKET: PUSH-ROD
OE94-00139-0100 SPRING PLATE: BOTTOM-RAMP, RT.
16 AE94-00024-0000 EXI TRAMP ASSY. : LT.
17 AE94-0050B-OOXF PLATFORM W/INSERTS-
18 AE94-00050-0000 TEAR-DROP ASSY. (LOCATED UNDER TOP PLATFORt-'l)
19 AE94-00051-0000 SCOP - ASSY. : INSIDE. LT
20 AE94-00052-0000 SCOOP - ASSY.: OUTSIDE. LT
21 AE94-00053-0000 SCOOP - ASSY.: INSIDE, RT
22 AE94-00054-0000 SCOOP - ASSY. : OUTSIDE. RT
23 OE94-00115-000 SCOOP: LANE-ENTRANCE RAt~P
24 AE94-00049-0100 ~10LDED FLIPPER W/CAP ASSY. (WHITE) LT
25 AE94-00049-0200 MOLDED FLIPPER W/CAP ASSY. (WHITE) RT
26 A365-00312-0100 MOLDED FLIPER W/CAP ASSY. {WHITE} LT
27 A365-00312-0200 t·10LOED FLIPPER W/CAP ASSY. (WHITE) RT
6.3
