Page 78 - 1987_BALLY_ASPIRE

TOP PLAYFIELD ASSEMBLY W/PLASTICS - PARTS LISTPART NO. AE94-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 AE94-00011-00XF SCREENED PLASTICS SET W/BUSHING
OE94-00901-00XF BUTYRATE: SCREENED W/DIE-CUT
2 AE94-00013-0000 BALL-SCOOP ASSY. : CENTER (LOCATED UNDER TOP PLATFORM)
3 AE94-00025-0000 POWER-REPS ASSY.: REAR (LOCATED UNDER TOP PLATFORM)
4 AE94-00026-0000 POWER-REPS ASSY.: FRONT (LOCATED UNDER TOP PLATFORM)
5 AE94-00029-0000 LANE-ENTRANCE RAIL ASSY.,
AE94-00038-0000 TOP PLATFOR~1 ASSY.: (INCLUDES ITEMS 6 THRU 17)
6 AE94-00009-0000 BACKBOARD ASSY. (INCLUDES ITEf'.1S7 THRU 10)
7 .0,[94-00028-0000 BACKBOARD CABLE ASSY •
8 AE94-00505-00XF BACKBOARD: SCREENED W/INSERTS
9 OE52-00109-00XF BRKT. : GUSSET (2 REQ I D. )
10 SEE COM~10N SOCKET ASSY. (SEE PAGE 40)
11 AE94-00014-0000 BALL-SCOOP ASSY.: UPPER LT.
12 AE94-00015-0000 BALL-SCOOP ASSY.: UPPER RT.
13 AE94-00016-0000 BALL-SCOOP ASSY. : TOP
14 AE94-00019-0000 RAf4P ASSY.: LT. (INCLUDES FOLLOWING 5 ITENS)
OE94-00109-0000 LEFT RA~1P
OE94-00128-00XF BRACKET: RAt1P
OE94-00129-0000 RAMP TOP: SPRI NG
OE94-00131-00XF BRACKET: PUSH-ROD
OE94-00139-0200 SPRING PLATE: BOTTOH-RAMP, LT.
