BOTTOM PLAYFIELD ASSEMBLY - PARTS LIST, CONT'D.PART NO. A[79-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
16 A360-00239-000 SWITCH W/BRKT. & DIODE ASSY. SLINGSHOT (2 REQ '0.)
A360-00069-0000 SWITCH ASSY.
17 A360-00241-0000 SWITCH W/DIODE & PLATE ASSY.
A360-00055-0000 SWITCH ASSY.
18 A365-00035-0000 SWITCH W/DIOE & PLATE ASSY. (2 REQ'D.)
A360-00243-0000 SWITCH W/DIODE ASSY.
A360-00061-0000 SWITCH ASSY.
19 A967-00067-000 SWITCH ~l/DlODE, PLATE ASSY. (2 REQ'D.)
A360-00065-0000 SWITCH ASSY.
20 A365-00036-0000 SWITCH W/DIODE & PLATE ASSY. (2 REQ'D.)
A967-00068-0000 SWITCH W/DIOE ASSY.
A967-0007S-0000 SWITCH ASSY.
21 AAI7-00041-0000 SWITCH W/DIODE & PLATE ASSY. (4 REQ'0 •)
AA17-00040-0000 SWITCH W/DIODE ASSY.: ROLLOVER BUTTON
A390-00040-0000 SWITCH ASSY.: ROLLOVER BUTTON
22 OB42-00100-00XF BALL CONTROL PLATE
23 OB42-00102-00XF BRKT.:BOTTOM ARCH (2 REQ'D.)
24 OE35-001lS-00XF BALL RUNvlAY
25 0017-00003-0103 FUSE: MDL 3AG lA 250V SLOW-BLOW (3 REQ'O.)
26 0365-00170-01XF HINGE PLATE: PLAYFIELO RT. (2 REQ'D.)
27 0365-00170-02XF HINGE PLATE: PLAYFIELD LT. (2 REQ'D.•)
28 0720-00001-0100 FUSE-CLIP ASSY. 1-POSITION (3 REQ'O.)
5.13
