BOTTOM PLAYfIElD ASSEMBLY - PARTS LISTPART NO. AE79-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 AA40-00019-0000 BALL GATE ASSEt·1BLY
2 AA40-00027-0000 BALL CHMJNEL GATE ASSEMBLY (SEE PAGE 32)
.3 AC70-00022-0200 FLI PPER ASSY. SINGLE SWILT . (SEE PAGE 22 )
4 AC70-00023-0100 FLIPPER ASSY. DOUBLE SW/RT. (SEE PAGE 24)
5 AE79-00005-0000 PLAYFIELO CABLE ASSY.
6 AE79-00027-0000 EJECT HOLE ASSY. (SEE PAGE 30)
7 AE79-00039-0000 EJECT HOLE ASSY. (SEE PAGE 30)
8 AE79-00036-0000 FLIPPER ASSY. RT. W/O SWITCH (SEE PAGE 28)
9 A967-00053-0100 THUt·1PER BUMPER ASSY. (3 REQ'O.) (SEE PAGE 14)
10 A967-00059-0000 SLINGSHOT KICKER ASSY. (2 REQ'O.) (SEE PAGE 16)
11 A360-00235-0000 KNOCKER A.SSY. 2-LUG (SEE PAGE 7 )
12 A365-R0307 -F 113 TARGET, SWITCH, BRKT. , DIODE & CAP (YELOVJ) LG-RT (2 REQ'O.)
A365-R0300-0003 TARGET W/SWITCH ASSY. (YELLOW) (3 REQ'O.)
A360-00070-0000 SWITCH ASSY. : TARGET
13 A331-00042-0000 BRKT. W/WIRE FOR~l ASSY. ROLLOVER LT. (2 REQ'O.)
0360-00135-0000 BRKT. : ROLLOVER-WIRE, LT.
0360-00929-0200 WIRE FORt": ROLLOVER, LT.
14 A360-00216-0000 BRKT. W/WIRE FORt·1 ASSY. ROLLOVER RT. (2 REQ'O.)
0360-00134-0000 BRKT. : ROLLOVER-'..JIRE. RT.
0360-00930-0000 tHRE fORM: ROLLOVER, RT.
15 A.360-00217-0000 BRKT. W/WIRE FORM ASSY. ROLLOVER LT.
0360-00135-0000 BRKT .: ROlOVER-IHRE, LT.
0360-00931-0000 \JIRE-FORf<1: ROLLOVER, LT.
5 .12
