Page 57 - 1987_BALLY_ASPIRE

BOTTOM PLAYFIELD ASSEMBLY - PARTS LISTPART NO. AE35-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 AA40-00019-0000 BALL-GATE ASSY.
2 AA40-00027-0000 BALL CHANNEL GATE ASSErtBLY (SEE PAGE 29 )
3 AC70-00022-0100 FLIPPER ASSY. SINGLE SWIRl. (SEE PAGE 24)
4 AC70-00022-0200 FLIPER ASSY. SINGLE SW/LT. (SEE PAGE 22)
5 AC70-00023-0100 FLIPPER ASSY. DOUBLE SW/RT. (SE PAGE 26)
6 AE35-00005-0000 PLAYFIELD CABLE ASSY.
7 AE35-00012-0000 KICKER ..• POST ASSY. (SEE PAGE 31)
8 SEE Cor~MON SOCKEI ASSY. (PAGE 28 )
9 AE35-00043-0000 BALL STOP & COIL ASSY. (SEE PAGE 33)
10 A365-R0307-F113 TARGET~ SWITCH ~ BRKT. ~ DIODE & CAP: (YELLOW) (2 REQ'D.)
A365 ...R0300-0003 TARGET~ W/SWITCH ASSY. (YELLOW) LUG-RT. (6 REQ'O.)
A360-0007 -0000 SWITCH ASSY. LUG ..• RIGHT
11 AE35-00061-0000 5-BALL TROUGH CABLE ASSY.
12 A331-00042-0000 BRKT. W/WIRE-FOR~1 ASSY. : LT (5 REQ'D. )
0360-00135-0000 BRKT. : ROLLOVER WIRE, LT. (5 REQ I O. )
0360-00929-0200 WIRE FORM: ROLLOVER, LT. (5 REQ'D.)
13 A360-00216-0000 BRKT. W/WIRE-FORM ASSY. : RT. (2 REQ I D. )
0360-00134-0000 BRKT. : ROLLOVER WIRE, RT. ( 2 REQ'D.)
0360-00930-0000 WIRE FORH: ROLLOVER. RT. ( 2 REQIO. )
14 A360-00217-0000 BRKT. W/WIRE-FORM ASSY. : LT.
0360-00135-0000 BRKT. : ROLLOVER WIRE, LT.
0360-00931-0000 WIRE FORH: BAL RETURN
15 A360-00230-0 00 SWITCH W/BRKT. & PLATE ASSY. : SLINGSHOT (2 REQ'D.)
A360-00069-0000 SWITCH ASSY.
16 A360-00235-0000 KNOCKER ASSY. (SE PAGE 7)
17 A360-00239-0000 SWITCH W/BRKT. & DIODE ASSY. : SLINGSHOT (3 REQ I D. )
