TOP PLAYFIElD ASSEMBLY W/PlASTICS - PARTS LIST" CONTID.PART NO. AE35-00004-0000
ORDER BY PART NUt·1BER ONLY
ITEM PART NO. DESCRIPTION
0365-00970-0002 WIRE FORM: MICRO-SWITCH
14 OE35-00920-00XF WIREFORM: BALL GUIDE
AE35-00031-0000 MICRO-SWITCH & BRKT. ASSY. (INCLUDES ITEt~ 15)
15 AE35-00032-0000 MICRO-SWITCH & WIRE ASSY •. (UNDER PLASTIC)
0017-00007-0015 NUT: 118 PUSH
0017-00032-0123 SWITCH: LOW-TORQUE
0365-00970-0001 WIRE FORM: MICRO-SWITCH
16 OE35-00928-00XF COVER: REAR ATOM SMASHER, DIE-CUT
17 AE35-0033-0000 ATOM-SMASHER RUNWAY & LIMITER ASSY.
18 OE35o.:00927-0001 DECAL: ANTI-GRAVITY, DIE-CUT
19 AE35-00036-0000 ATOM-SMASHER FRONT-ENTRANCE ASSY. (UtJDER PLASTIC)
20 OE35-00912-00XF COVER: ATOM st4ASHER, DIE-CUT
21 OE35-00927-0002 DECAL: ATOM SMASHER, DIE-CUT
22 0017-00009-0302 ACORN NUT (10 REQ'D.)
23 AE35-00071-0000 CAP & SPACER ASSY. (3 REQ'D.) (INCLUDES FOLLOWING 2 ITEMS)
AE35-00050-0000 CAP: THUMPER BUMPER W/HOT STAMP
0017-00042-0734 SPACER: SELF-RETAINING (2 REQ'D.)
24 SEE COMMON SOCKET ASSY. (PAGE 28)
25 A365-00312-0200 MOLDED FLIPPER-CAP ASSY. (WHITE) RT.
26 A365-00312-0300 MOLDED FLIPPER-CAP ASSY. (BLACK) LT.
27 A365-00312-0400 MOLDED FLIPPER-CAP ASSY. (BLACK) RT.
28 OE35-00142-00XF SHOOTER GAUGE
4.3
