Page 49 - 1987_BALLY_ASPIRE

TOP PLAYFIElD ASSEMBLY W/PlASTICS - PARTS LIST
PART NO. AE35-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 AE35 ...00011-00XF SCREENED PLASTICS SET W/BUSHING
OE35-0091-00XF BUTYRATE: SCREEND DIE-CUT
2 OE35-00140-0000 PLATE: RAt1P ENTRANCE PARTICLE SEPARATOR RT.
3 OE35-00147-0000 PLATE: RAMP ENTRANCE PARTICLE SEPARATOR LT. --
4 O£35-00927-0000 DECAL: PARTICLE SEPARATOR
5 AE35-00019-0000 ANTI-GRAVITY RAMP ASSY.
AE35-00021-0000 BACKBOARD ASSY. : PLAYFIELD (INCLUDES ITEMS 6 THRU 12l
6 AE35-00023-0000 SWITCH W/BRKT. , DIODE & PLATE (3 REQ'D.l
A360-00061-0000 SWITCH ASSY. (3 REQID.)
-
OE35-0 132-0000 BRKT. : ROLLOVER SHITCH MTG. (3 REQ ID. )
0017 ...00101-0526- 5-40 X 9 PHILLIPS PAN MACHINE SCREW (6 REQID. )
0020-00202-0000 PLATE: SWITCH (3 REQ'D.)
7 AE35-00024-0000 BRKT. W/WIRE-FORM ASSY. : LT. (3 REQID. )
OE35-00916-0000 WIRE FORM: ROLLOVER LT. (3 REQ'D. )
0360-00135-0000 BRKT.: ROLOVER WIRE, LT. (3 REQ' D. )
8 AE35-00034-0000 ATOM-SMASHER REAR RA~1P-ENTRM~CE ASSY.
9 AE35-00048-0000 BACKBOARD CABLE ASSY.
10 AE35-00502-000 BACKBOARD: SCREE~JED OW/INSERT
11 OEI4-00103-00XF BRKT. : GUSSET (2 REQ' D. )
12 OE35-00133-0000 BRKT. : BUTYRATE-SUPPORT (3 REQID.)
AE35-00028-0000 ATOf1-SMASliER f~ULTI ..BALL ASSY. (INCLUDES ITEMS 13 & 14)
13 AE35-00030-0000 M ICRO-SW ITCH W/WIRE & DIODE ASSY.
0017-00007-0015 NUT: 1/8 PUSH
0017-00032-0123 SWITCH: LOW-TORQUE --
4 .2
