BOTTOM PLAYFIELD ASSEMBLY - PARTS LIST, CONT'D.
PART NO. AE47-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
34 OA40-00116-00XF PAWL (3 REQ'D. )
35 0017-00100-0175 RING: E .156" 5133-15 (3 REQ'D.)
36 0017-00101-0175 6-32 X 4 PHILLIPS PAN HD. SCREW (2 REQ'D. )
37 A360-00234-0000 TOP-MOUNTED KICKER ASSY.
38 OA40-00122-00XF BALL RUNWAY
39 AE47-00042-0000 SWITCH W/TARGET, BRKT. , AND DIODE ASSY.
AE47-00044-0000 SWITCH W/TARGET ASSY.
OE47-00114-00XF BRACKET: SWITCH
40 AA40-00019-0000 BALL GA.TE ASSY.
41 B084-91618-AOOO SOLENOID - EXPANDER BOARD
42 0720-00001-0100 FUSE CLIP ASSY.
43 OA40-00l25-00XF STRAP: METAL TIE
44 A360-00245-0l00 SPINUER S~~ITCH• DIODE & PLATE ASSY.
A360-00058-0000 SWITCH ASSY.
45 AE47-00042-0000 SWITCH W/TARGET SPECIAL, BRKT •• DIODE & CAP ASSY.
- AE47-00044-0000 SWITCH W/TARGET ASSY.
OE47-00114-00XF BRKT. : TARGET
3.13
