J128 Not Used
J129 Not Used
J130-1 Violet-Brown Sol 1 to playfield coil
J 130-2 Violet-Red Sol 2 to playfield coil
J130-3 Key
J130-4 Violet-Orange Sol 3 to playfield coil
J 130-5 Violet-Yellow Sol 4 to playfield coil
J130-6 Violet-Green Sol5 to playfield coil
J130-7 Violet-Blue Sol6 to playfield coil
J130-8 Violet-Black Sol 7 to back box coil
J 130-9 Violet-Gray Sol 8 to playfield coil
J131 Not Used
J132 Not Used
J 133 Not Used
J134-1 Not Used
J134-2 Not Used
J134-3 Key
J134-4 Not Used
J134-5 Not Used
J134-6 Not Used
J 134-7 Red-Blue Row 6 to cabinet lamp
J134-8 Red-Violet Row 7 to cabinet lamp
J134-9 Red-Gray Row 8 to cabinet lamp
3-27
J135-1 Red-Brown Row 1 to playfield lamps
J 135-2 Red-Black Row 2 to playfield lamps
J135-3 Key
J135-4 Red-Orange Row 3 to playfield lamps
J 135-5 Red-Yellow Row 4 to playfield lamps
J135-6 Red-Green Row 5 to playfield lamps
J135-7 Red-Blue Row 6 to playfield lamps
J 135-8 Red-Violet Row 7 to playfield lamps
J135-9 Red-Gray Row 8 to playfield lamps
J136-1 Key
J136-2 Not Used
J136-3 Yellow-Gray Col 8 to insert lamps
J137 Not Used
J 138-1 Yellow-Brown Col 1 to playfield lamps
J 138-2 Yellow-Red Col 2 to playfield lamps
J138-3 Yellow-Orange Col3 to playfield lamps
J138-4 Yellow-Black Col4 to playfield lamps
J 138-5 Yellow-Green Col 5 to playfield lamps
J138-6 Yellow-Blue Col6 to playfield lamps
J138-7 Yellow-Violet Col 7 to playfield lamps
J138-8 Key
J138-9 Yellow-Gray Col 8 to playfield lamps
