RAISING THE PLAYFIELD
&
CAUTION
Do not raise the playfield straight up! This game uses a slide assembly to raise and
lower the playfield.
To raise the playfield.
1. Grasp bottom arch and carefully lift up playfield
only high enough to clear safety brackets. Rear
guide legs should not hit wood guide rails or be
used to slide out playfield.
Bottom Arch
Rear Guide Leg
(2 used)
Wood Guide Rail
(2
used)
To lower the playfield.
4. Rotate the playfield to the rest position.
This unlocks the pivoting mechanism.
S. Push back playfield into cabinet and into
playing position.
2. Pull the playfield out toward you until
it
stops
(rest position) and raise
it
approximately3".
Be sure playfield is in locked
position and does not slide back
into the cabinet. If it does, repeat
Step 2 before proceeding to Step 3.
3. Rotate playfield to upright service position
(lean on backbox) by pulling toward you and
up. Listen for the sound of a click; this
insures locking and pivoting sequence.
Pivol Mechanism
(2 used)
Twilight Zone 1-5
Safety Bracket
(2
used)
