DOT MATRIX CONTROLLER BOARD
A-14039
('II
..,.
JS03
c=:;:;f
~
JS01
2
10
20
30
JS02
'~:
JS06
TI
J604,
I I
1S05
1
8
1 5
1
J605-1 White, 80VAC from transformer secondary
J605-2 White, 80VAC from transformer secondary
J605-3 Violet, 1OOVAC from transformer secondary
J605-4 Key
J605-5 Violet, 1OOVAC from transformer secondary
J602 Ribbon Cable, Data from J201
J601 Ribbon Cable, Data to/from J202; J903; J506
J603 Ribbon Cable ,Data to Dot Matrix Display Driver
J604-1 Orange, -125V to Dot Matrix Display Driver Pin 1
J604-2 Blue, -113V to Dot Matrix Display Driver Pin 2
J604-3 Key
J604-4 Black, Ground to Dot Matrix Display Driver Pin 4
J604-5 Black, Ground to Dot Matrix Display Driver Pin 5
J604-6 Gray,
+5V
to Dot Matrix Display Driver Pin 6
J604-7 Gray-Yellow,
+
12V
to Dot Matrix Display Driver Pin 7
J604-8 Brown, +62 to Dot Matrix Display Driver Pin 8
J606-1 Black, Ground loop from J606-3
J606-2 Key
J606-3 Black, Ground from J117-3
J606-4 Gray, +5V loop from J606-5
J606-5 Gray, +5V from J117-4
J606-6 Gray-Yellow, +
12V
loop from J606-7
J606-7 Gray-Yellow,
+12V
from J117-2
P,C, Board Legend
J1.J6 CoinDoor InterfaceBoard
J1xx PowerDriverBoard
J2XX CPUBoard
J5xx AudioBoard
J6xx DotMatrixControllerBoard
J9xx Fliptronic II Board
Twilight Zone 3-36
