SOUND BOARD
A-12738-50020
J506
1~2 10
20
30
lij:
0>
.[]:
5l
""')
[ID:
I
J501
7
J501-1 Gray-Green, 20VAC from transformer secondary
J501-2 Gray-Green,
loop from J501-1
J501-3 Key
J501-4 Gray, 20VAC from transformer secondary
J501-5 Gray, 20VAC loop from J501-4
J501-6 Gray-White, 20VAC loop from transformer secondary
J501-7 Gray-White, 20VAC loop from J501-6
J502-1 Gray, +5VDC from J114-4
J502-2 Key
J502-3 Gray, +5VDC from J114-3
J502-4 Black, Ground from J114-7
J502-5 Black, Ground from J114-5
J503 Not Used
J504-1 Not Used
J504-2 Not Used
J504-3 Black, Signal to speaker
J504-4 Not Used
Twilight Zone 3-35
J505-1 Not Used
J505-2 Black-Yellow, Signal to speaker
J505-3 Not Used
J505-4 Not Used
J506 Ribbon Cable, Data to/from J601; J903; J202
J507 Not Used
J508 Not Used
J509 Not Used
p.C. Board Legend
J1.J6 Coin Door Interface Board
J1XX Power Driver Board
J2XX CPU Board
J5XX Audio Board
J6xx Dot Matrix Controller Board
J9XX Fliptronic " Board
