POWER DRIVER BOARD CONTINUED ....
J11S-1 Yellow-White, 6.BVAC from transformer secondary
J11S-2 White-Brown, 6.BVAC from transformer secondary
J11S-3 White-Brown, loop from J11S-2
J 11S-4 White-Orange, 6.8VAC from transformer secondary
J11S-S White-Yellow, loop from J11S-6
J11S-6 White-Yellow, 6.8VAC from transformer secondary
J11S-7 Orange, 6.8VAC from transformer secondary
J11S-8 Orange, 6.BVAC loop from J11S-7
J11S-9 Key
J11S-10 Green, 6.BVAC from transformer secondary
J11S-11 Brown, 6.8VAC from transformer secondary
J11S-12 Brown, 6.8VAC loop from J11S-11
J116-1 Key
J116-2 Gray-Yellow, + 12VDC to coin door; J2-4
J116-3 Black, Ground to coin door; J2-S
J116-4 Not Used
J117-1 Key
J117-2 Gray-Yellow, +12VDC to J606-7
J117 -3 Black, Ground to J606-3
J117 -4 Gray, +SVDC to J606-S
J118-1 Key
J 11S-2 Gray-Yellow, +12VDC playfieldlcabinet
J11S-3 Black, Ground
J11S-4 Not Used
J119-1 White-Violet, 6.8VAC G.I. to coin door; J2-2
J119-2 Key
J119-3 Violet, Return G.I. to coin door; J2-1
J120-1 Not Used
J120-2 Orange, Return G.I. to insert
J120-3 Yellow, Return G.I. to insert
J120-4 Key
J120-S Green, Return G.I. to insert
J120-6 Not Used
J120-7 Not Used
J120-8 White-Orange, 6.8VAC to insert
J120-9 White-Yellow, 6.SVAC to insert
J120-10 White-Green, 6.8VAC to insert
J120-11 Not Used
J121-1 Brown, Return G.I. to playfield
J121-2 Orange, Return G.I. to playfield
J121-3 Yellow, Return G.I. to playfield
J121-4 Key
J121-S Not Used
J121-6 Violet, Return G.I. to playfield
J121-7 White-Brown, 6.8VAC to playfield
J121-S White-Orange, 6.8VAC to playfield
J121-9 White-Yellow, 6.8VAC to playfield
J121-10 Not Used
J121-11 White-Violet, 6.SVAC to playfield
J122 Not Used
J123 Not Used
J124-1 Blue-Brown, Sol2S to playfield magnet
J124-2 Blue-Red, 50126 to playfield magnet
J124-3 Blue-Orange, 50127 to playfield coil
J124-4 Key
J124-S Blue-Yellow, Sol 28 to playfield flasher
J12S-1 Black-Brown, 50117 to playfield flasher
J12S-2 Black-Red, Sol 18 to playfield flasher
J12S-3 Black-Orange, 50119 to playfield flasher
J12S-4 Key
J12S-S Black-Yellow, 50120 to playfield flasher
J125-6 Blue-Green, Sol21 to playfield magnet
J125-7 Not Used
J12S-8 Blue-Violet, Sol 23 to playfield magnet
J12S-9 Blue-Gray, Sol 24 to playfield motor
J126 Not Used
J127 -1 Brown-Black, Sol 9 to playfield coil
J127-2 Key
J127-3 Brown-Red, Sol 10 to playfield coil
J127-4 Brown-Orange, 50111 to playfield coil
J127-S Brown-Yellow, 50112 to playfield coil
J127-6 Brown-Green, 50113 to playfield coil
J127-7 Brown-Blue, 50114 to playfield coil
J127-8 Brown-Violet, 50115 to playfield coil
J127-9 Brown-Gray, Sol 16 to playfield coil
J12S Not Used
J129 Not Used
J130-1 Violet-Brown, 5011 to playfield coil
J130-2 Violet-Red, 5012 to playfield coil
J130-3 Key
J130-4 Violet-Orange, Sol 3 to playfield coil
J130-S Violet-Yellow, Sol 4 to playfield coil
J130-6 Violet-Green, 5015 to playfield coil
J 130-7 Violet-Blue, Sol 6 to playfield coil
J130-S Violet-Black, Sol 7 to playfield coil
J130-9 Violet-Gray, Sol 8 to playfield coil
J131 Not Used
J132 Not Used
p.C Board Legend
Jhl6 CoinDoorInterfaceBoard
J1xx PowerDriverBoard
J2xx CPUBoard
J5xx AudioBoard
J6xx DotMatrixControllerBoard
J9xx FliptroniCII Board
Twilight Zone 3-33
