POWER DRIVER BOARD
A-12697-3
J101-1 Red, 9VAC from transformer secondary
J1 01-2 Red, 9VAC from transformer secondary
J101-3 Key
J1 01-4 Blue-White, 13VAC from transformer secondary
J101-5 Blue-White, loop from J101-4
J 101-6 Blue-White, 13VAC from transformer secondary
J101-7 Blue-White, loop from J101-6
J102-1 White-Red, loop from J102-2
J102-2 White-Red, 16VAC from transformer secondary
J102-3 White-Red, loop from J102-4
J102-4 White-Red, 16VAC from transformer secondary
J102-5 Black-Yellow, loop from J102-6
J1 02-6 Black-Yellow, 16VAC from transformer secondary
J102-7 Key
J102-8 Black-Yellow, loop from J102-9
J1 02-9 Black-Yellow, 16VAC from transformer secondary
J103-1 Black, Ground to J2-5, A-16100
J103-2 Black, Ground to J2-4, A-161 00
J103-3 Black, Ground to J2-1, A-16116
J103-4 Black, Ground to J2-2, A-16116
J104 Not Used
J105-1 White-Blue, 50VACtoJ901-1
J105-2 White-Blue, 50VAC to J901-3
J105-3 Key
J105-4 Not Used
J105-5 Not Used
J106 Not Used
J107-1 Not Used
. J1 07-2 Violet-Orange, 50V to playfield coils
J1 07 -3 Violet-Yellow, 50V to playfield coils
J107-4 Key
J107-5 Red, +20V to playfield flash lamps
J107-6 Red-White, +20V to playfield flashlamps
J108 Not Used
J109-1 Not Used
J109-2 Not Used
J109-3 Not Used
J109-4 Not Used
J109-5 Violet-Green, 50V to playfield coils
J109-6 Key
J109-7 Violet-White, 50V to playfield coils
J110 Not Used
J111 Not Used
'· ',. . ._ r
!aaaa! laacaDa •• al
,
4'
9
J103 J102
!a •• aoCiDI
,
7
J101
rn
...~
-
"")
_
"'"[IT
C\I •
-
.
-') :
.0
~llJ:_ ~
...,.
-
.
"'...,
[fl '" -
-
-
_"")
J113
J114
J115
301
1 ••••••••
_ •••••••
1 '
E3
I
I
33.----.2
aaa.DDQDDDDD
7
1 12·
.,
J112-1 White-Green, 9.8VAC from transformer secondary
J112-2 White-Green, loop from J112-1
J112-3 White-Green, 9.8VAC from transformer secondary
J112-4 Key
J112-5 ~fhite-Green, loop from J112-3
J113 Ribbon Cable, Data tolfrom J211
J114-1 Gray/Green, +12VDC to J21 0-7
J114-2 Not Used
J114-3 Gray, +5VDC to J21 0-5; J502-3
J114-4 Not Used
J 114-5 Not Used
J114-6 Key
J114-7 Black, Ground to J210-1; J502-4; J904-4
-~-,.-
...•
,.,--
p.c.
Board Legend
J1·J6 CoinDoor InterlaceBoard
J1XX PowerDrtverBoard
J2XX CPUBoard
J5xx AudioBoard
J6XX DotMatrixControllerBoard
J9XX FI_'tronlCII Board
Twilight Zone 3-32
