CPU BOARD
A-12742-50020
J201 Ribbon Cable, Data to J602
J202 Ribbon Cable, Data to J903; JS06; J601
J203 Not Used
J204 Ribbon Cable, Data to J1, A-16100
J20S-1 Orange-Brown, Dir Sw 1, Left Coin to J1-14
J20S-2 Orange-Red, Dir Sw 2, Center Coin to J1-13
J20S-3 Orange-Black, Dir Sw 3, Right Coin to J1-12
J20S-4 Orange-Yellow, Dir Sw 4, 4th Coin J1-17
J20S-S Key
J20S-6 Orange-Green, Dir Sw S, Escape/Service to J1-11
J20S-7 Orange-Blue, Dir Sw 6, DownNolume Down to J1-10
J20S-S Orange-Violet, Dir Sw 7, UpNolume Up to J1-9
J20S-9 Orange-Gray, Dir Sw S, EnterlTest to J1-S
J20S-10 Black, Ground to J1-1S
J20S-11 Not Used
J20S-12 Orange-White, Enable to J1-1S
J206-1 Green-Brown, Sw Col 1 to Playfield Switches
J206-2 Green-Red, Sw Col 2 to Playfield Switches
J206-3 Green-Orange, Sw Col 3 to Playfield Switches
J206-4 Green-Yellow, Sw Col4 to Playjield Switches
J206-S Green-Black, Sw Col S to Playfield Switches
J206-6 Green-Blue, Sw Col 6 to Playfield Switches
J206-7 Green-Violet, Sw Col 7 to Playfield Switches
J206-S Key
J206-9 Green-Gray, Sw Col 8 to Playfield Switches
J207 Not Used
J20S-1 White-Brown, Sw Row 1 to Playfield Switches
J208-2 White-Red, Sw Row 2 to Playfield Switches
J20S-3 White-Orange, Sw Row 3 to Playfield Switches
J20S-4 White-Yellow, Sw Row 4 to Playfield Switches
J20S-S White-Green, Sw Row S to Playfield Switches
J20S-6 Key
J20S-7 White-Blue, Sw Row 6 to Playfield Switches
J208-8 White-Violet, Sw Row 7 to Playfield Switches
J20S-9 White-Gray, Sw Row S to Playfield Switches
J209 Not Used
J210-1 Black, Ground from J114-7
J210-2 Key
J210-3 Black, Ground from J114-S
J210-4 Gray, +SVDC from J114-4
J210-S Gray, +SVDC from J114-3
J21 0-6 Gray-Green, + 12VDC from J114-2
J210-7 Gray-Green, +12VDC from J114-1
o
"'[]]o ~
••••••
(.0)
o
'" '"
0>'"
o
J212 J206 J208
i80"'ooo~
1•••
00000°1
(oo_ooooo~
J205 9 J207 ~ J209
~ ••• ooooooOOi
1"'0000001 1000ll00000j
12
19
1 9
1
J211 Ribbon Cable, Data from J113
o
o
J212-1 Green-Brown, SwCol1 toJ1-1
J212-2 Green-Red, Sw Col 2 to J1-7
J212-3 Not Used
J212-4 White-Brown, Sw Row 1 to J1-6
J212-S Key
J212-6 White-Red, Sw Row 2 to J1-S
J212-7 White-Orange, Sw Row 3 to J 1-4
J212-S White-Yellow, Sw Row 4 to J1-3
poCo
Board Legand
JhJ6 CoinDoorInterfaceBoard
J1xx PowerDrtverBoard
J2xx CPUBoald
J5xx AudioBoald
J6xx DotMatrixControllerBoard
J9xx FliptronlcII Board
Twilight Zone 3-29
