FLIPTRONIC II BOARD
A-15472
110 0 0 0 0 0 0 0 0
*
0 0 0113
J902
~
J9~
~I
L-__
J:..:9..:..:03=---_-l1~ 1 0 0
*
0 01
5
1
J901-1 White-Blue, 50VAC loop fromJ104-1
J901-2 White-Blue, loop from J901-1
J901-3 White-Blue, 50VAC loop, from J1 04-2
J901-4 Key
J901-5 White-Blue, loop from J901-3
J902-1 Orange-Gray,
holding to upper left flipper
J902-2 Not Used
J902-3 Black-Blue, power to upper left flipper
J902-4 Orange-Violet, holding to upper right flipper
J902-5 Not Used
J902-6 Black-Yellow, power to upper right flipper
J902-7 Orange-Blue, holding to lower left flipper
J902-8 Not Used
J902-9 Blue-Gray, power to lower left flipper
J902-10 Key
J902-11 Orange-Green, holding to lower right flipper
J902-12 Not Used
J902-13 Blue-Violet, power to lower right flipper
J903 Ribbon Cable, data to/from J202; J506; J601
J904-1 Gray, +5V from J114-4
J904-2 Gray-Green, +12V from J114-2
J904-3 Key
J904-4 Black, Ground from J114-7
J904-5 Black, Ground from J114-5
r-- ~
0
0
•....
*
0
s
0
...,
0
0
0
~O>
grn: ~
...,*
o
It)
~J905
-
f1_
100*000110000*01
u
6
1 6
1
J905-1 Blue-Violet, to right flipper opto
J905-2 Blue-Gray, to left flipper opto
J905-3 Black-Yellow, to right flipper opto
J905-4 Key
J905-5 Black-Blue, to left flipper opto
J905-6 Orange, Switch Ground
J906-1 Black-Green, to lower right end-of-stroke switch
J906-2 Key
J906-3 Black-Blue, to lower left end-of-stroke switch
J906-4 Black-Violet, to upper right end-of-stroke switch
J906-5 Black-Gray, to upper left end-of-stroke switch
J906-6 Orange, Switch Ground
J907-1 Blue-Yellow, +50V to lower right flipper
J907-2 Blue-Yellow, loop from J907-1
J907-3 Key
J907 -4 Gray-Yellow, +50V to lower left flipper
J907-5 Gray-Yellow, loop from J907-4
J907-6 Blue-Yellow, +50V to upper right flipper
J907-7 Blue-Yellow, loop from J907-6
J907-8 Gray-Yellow, loop from J907-9
J907-9 Gray-Yellow, +50V to upper left flipper
P C, Board Lagend
J1.J6 CoinDoor InterfaceBoard
J1)()( PowerDriverBoard
J2xx CPUBoard
J5)()( AudioBoard
J6XX Dot MatrixControllerBoard
J9xx FliptronicII Board
Twilight Zone 3-28
