OPTO SW7 p.e.B.
A·15576
0
:m3=~
0
I ~
<-
nO
OLEOl
'"
~
•
aDD
<JIiiD ..,
0
<Ii[) ,
0
~
c~
<liD
-®-
<ID
=
cnDD
-QiD-
@l>
N
~
.
-
-QD-
-[§J--
0
-@]-
0
J1-1 Not Used
J1-2 Gray-Blue to A-14231 (LED) J1-7 Sw #36
J1-3 Gray-Green to A-18617-1 (LED) J1-3 Sw #34
J1-4 Key
J1-5 Gray-Black to A-18617-1 (LED) J1-4 Sw #33
J1-6 Gray-Orange to A-18617-1 (LED) J1-5 Sw #32
J1-7 Gray-Red to A-18617-1 (LED) J1-6 Sw #31
J1-8 Gray-Brown to A-18617-1 (LED) J1-7 Sw #35
J
1-9 Not Used
J1-10 Black Ground to A-18617-1 J1-10
J2-1 Not Used
J2-2 Orange-Blue to A-14232 (Photo) J1-3 Sw #36
J2-3 Orange-Green to A-18618-1 (Photo) J1·7 Sw #34
J2-4 Orange-Yellow to A-18618-1 (Photo) J1-6 Sw #33
J2-5 Orange-Black to A-18618-1 (Photo) J1-5 Sw #32
J2-6 Orange-Red to A-18618-1 (Photo) J1-4 Sw #31
J2-7 Orange-Brown to A-18618-1 (Photo) J1-3 Sw #35
J2-8 Key
J2-9 Not Used
J2-10 Gray-Yellow +12VDC to A-18618 (Photo) J1-1
J3-1 Not Used
CPU
BOARD
J209
POWER DRIVER BOARD
-Repect 6 times
Opto SW7 Circuit
3-18
J3-2 Gray-Yellow +12VDC from J116-2
J3-3 Black Ground from J116-3
J3-4 Key
J3-5 White-Brown from J209-1
J3-6 White-Red from J209-2
J3-7 White-Orange from J209-3
J3-8 White- Yellow from J209-4
J3-9 White-Green from J209-5
J3-10 White-Blue from J209- 7
J3-11 Not Used
J3-12 Green-Orange from J207-3
OPTO
SW7
P C.B.
A-15576
Jl
