TROUGH IRED TRANSISTOR p.e.B. ASSEMBLY
A-18618-1
J1-1 Gray-Yellow, from Opto SW7 Board J2-10
J1-2 Key
J1-3 Orange-Brown, from Opto SW7 Board J2-7
J1-4 Orange-Red, from Opto SW7 Board J2-6
J1-5 Orange-Black, from Opto SW7 Board J2-5
J1-6 Orange-Yellow, from Opto SW7 Board J2-4
J1-7 Orange-Green, from Opto SW7 Board J2-3
J1-8 Not Used
J1-9 Not Used
o
o
®@
~ 01
(JAM BALL)
~~ Q2
1)
~
(BALL
03
(BALL 2)
~ 04
(BALL 3)
Trough 7 IR TSTR Circuit
3-17
LO,J, '
KEY
JAM BALL 2
'------='------------4
3
BAlL 1 4
BALL 2 5
BALL 3 6
BALL 4
NOT USED 7
_N_O_T_U_S_E---jD~
