T.3 Single Switches
Once the test name is shown under the Test Menu, press the Enter button. The Single Switch Test
isolates a particular switch by blocking signals from all other switches. Use the Up or Down
buttons to select the switch to be tested. Press the Start button to obtain wire color, connector,
and fuse information of any switch when that switch is displayed.
Press the Escape button to return to the Test Menu. Press the Up button to display the next test,
(or the Down button to return to a previous test). Press the Enter button to activate that test.
T.4 Solenoid Test
Once the test name is shown under the Test Menu, press the Enter button. The Solenoid Test has
three modes, Repeat, Stop, and Run. Only one solenoid should pulse at a time. The system has
detected a problem if, more then one solenoid pulses, a solenoid comes On and stays On, or no
solenoid pulses during the Repeat or Run test modes. Press the Start button to see the wire color,
driver number, connector, and fuse information for any coil.
Repeat-
The Repeat mode allows you to pulse a single solenoid. After entering this test,
Solenoid 1 shows in the display and the corresponding solenoid activates. Press the Up or Down
button to cycle through the solenoids, one at a time. The same solenoid pulses until you press the
Up or Down button to move to the next one. Either press the Escape button to return to the Test
Menu, or press the Enter button to move to the next mode.
Stop
The Stop mode allows you to stop the Solenoid Test. Press Enter during the Repeat
mode and the Solenoid Test stops. No solenoids should be activated while the test is stopped.
Either press the Escape button to return to the Test Menu, or the Enter button to move to the next
mode.
Run-
The Run mode allows you to cycle through the solenoids automatically. Press the
Enter button during the Stop mode. The display shows you the name and number of the solenoid
currently being pulsed.
Either press the Enter button to return to the Repeat mode, or press the Escape button to return to
the Test Menu. Once in the Test Menu press, the Up button to display the next test, (or the Down
button to return to a previous test). Press the Enter button to activate that test.
T.5 Flasher Test
Once the test name is shown under the Test Menu, press the Enter button. This tests the
flashlamp part of the solenoid circuit exclusively. This, like the Solenoid Test, has three modes,
Repeat, Stop, and Run. During this test, only one llashlamp circuit should pulse at a time. The
system has detected a problem if more then one circuit pulses, a circuit stays On, or no circuit
pulses during the Repeat or Run modes. Press the Start button to see the wire color. driver
number, connector, and fuse information of any Ilashlamp circuit.
Repeat -
The Repeat mode allows you to pulse a single Ilashlamp. Once you have entered
this test, the name and number of the first flashlamp circuit shows in the display and the
corresponding bulb(s) flashes.
Press the Up or Down button to cycle through all of the
flashlamps circuits one at a time. The same circuit pulses until you press the Up or Down button
to move to the next one. Either. press the Escape button to return to the Test Menu, or press the
Enter button to advance to the next mode.
Stop
The Stop mode allows you to stop the Flasher Test. Press the Enter button during
the Repeat mode. The Flasher Test stops. No flashlamp circuit should be turned On during this
mode. Either press the Escape button to return to the Test Menu, or press the Enter button to
advance to the next mode.
The Getaway 1-14
