T.7 Sound and Music Test
The Sound and Music Test checks the audio circuits. This test
has three modes for testing the sound and music circuits - Run, Repeat. and Stop.
Run: The Run mode steps through a sequence of sounds and music. Press the Up or
Down buttons during this portion of the Sound and Music test to advance to a particular
sound or tune without having to wait for the program to play all the sounds available in
the test. A sound or tune should be heard for each name and number that appears in
the display. Any other results indicates the system has detected a problem.
Repeat: Press the Enter button at any time during the Aun mode to cause the program
fa stop and repeat a partiCular soundltune. The same sound should repeat continuously
until the Up or Down button is pressed.
Any other results indicates the system has
detected a problem.
Stop:
Press the Enter button at any tkne during the Repeat mode to stop this test
altogether.
Nothing should be heard.
Any
other results indicates the system has
detected a problem.
T.8 Single Lamp Test
The number assigned to each lamp indicates the (amp's pOSition in the
matrix. The number on the left jndicates the column. The number on the right indicates the row.
Example - Lamp 23 means 2nd column.
3m
row.
This test checks each lamp circuit individually. Press the Up or Down button to cycle through this
test. For each name and number that is shown in the display the corresponding lamp should
light. Any other results indicates the system has deteded a probfem.
T.9 All
Lamps Test
This test causes all the controlled lamps to flash at the same time. Every
controlled lamp should flash. Any other results indicates the system has detected a problem.
T.10 Lamp and Flasher Test
This test causes all the flashlamps and the controlJed lamps to
flash at the same time. The controlled lamps blink. while the flash lamps eycre from highest to
lowest. Any other results indicates the system has detected a problem.
T.11 DisplayTest
This test automatically checks every dot in the Dot Matrix Display. A
series of patterns appear in sequence. Each pattern turns on and off a section of dots. "Every
dot on the matrix display should be turned on and off during this test.
T.12 Flipper Coil Test
The Flipper Coil Test has three modes - Repeat. StoP. and Run. Only
one Flipper should pulse at a time. The system has detected a problem
if
more then one flipper
pulses, a flipper comes on and stays on, or no flippers pulse during the Repeat or Run modes.
Repeat: The Repeat mode pulses a single flipper. After entering this test. flipper coif 01
shows in the display and the corresponding coil activates. Press the Up
Of
Down button
to cycle through the flipper coils, one at a time. The same soJenoid pulses until the Up or
Down button is pressed. Either press the Escape button to return 10 the Test Menu, or
press the Enter button to move to the next mode.
1-16
