T.4 Solenoid Test
The Solenoid Test has three modes - Repeat, Stop, and Run. Only one
solenoid
should
pulse
at a
time. The system
has
detected a problem if more then one solenoid
pulses, a solenoid comes
on
and stays on, or no solenoids pulse during 1he Repeat or Run
modes.
Repeat:
The Repeat mode pulses a single solenoid. After entering this test, Solenoid
1
shows
in
the display and the corresponding solenoid activates. Press the
Up
or Down
ootlon to cycle through the solenoids. one at a time. The same solenoid pulses until the
Up
or
Down button is pressed.
Either press the Escape button to return to the Test
Menu, or press the Enter button to move to the
next
mode.
Stop:
The Stop mode halts the Solenoid Test. Press Enter during the Repeat mode
and
the Solenoid Test stops. No solenoids should be activated while the test is stopped.
Either press the Escape button to return to the Test Menu. or the Enter button
to
move to
the next mode.
Run: The Run mode cycles through the solenoids automatically. The display shows the
name and number of the solenoid currently being pulsed.
T.S Flasher Test
This tests the flashlamp part of the solenoid circuit exclusively. This, like
the Solenoid Test has three modes - Repeat.
stoo,
and Run. During this test only one ffashlamp
circuit should pulse
at
a time. The system
has
detected a problem
if
more then one circuit
pulses, a circuit stays on, or no circuits pulse during the Repeat
or
Run modes.
. .,'
Repeat: The Repeat mode pulses a single flash lamp. After entering this test the name
and number of the first fJashlamp circuit shows in the display and the corresponding
bulb{s) flash. Press the
Up
or
Down
buttons to cycle through all of the
flash
lamps circuits
one at a time. The same circuit pulses until press the Up or Down button is pressed.
Either press the Escape button to return to
the
Test Menu, or
press
the Enter button to
advance to the next mode.
Stop:
The Stop mode halts the Flasher Test. No flash lamp circuit should be active
during this mode. Either press the Escape button to retum to the Test Menu, or press
the Enter button to advance to the next mode.
Run: The Run mode cycles through the flashlamps automatically.
The display shows
the name and number of the flashlamp circuit currently being pulsed as the
corresponding bulb(s) flashes.
,
T.6 GenerallUumination Test
This test checks aU of the General Illuminatiori Circuits.
There are two modes of operation - Stop and Run.
Stop:
Press the Up or Down buttons to cycle through the General Illumination Test
manually. All illumination is tested first, followed by an individual circuit test The circuit
name and
number
shows in the display while the corresponding lamps lights. If any other
results occur the system has detected an error.
Run: Press the Enter button any time during Stop mode and the General lllumination
Test cycles through automatically.
For each circuit shown in the display the
corresponding bulbs should fight. If any other results occurs the system has detected a
problem.
