8ackbox Assembly
9
Ribbon Cables
Item Part Number
Description
Item Part Number
Designator
1 01-6645
Venting Screen
10 5795-12653-03 Ribbon Cable, 34-pin, 3"
2 B-1 0686-1
Knocker Assembly
11 5795-12653-12 Ribbon Cable, 34-pin, 12"
3 A-14092-7
WPC '95 Mounting Plate Assy.
12 5795-13434-25 Ribbon Cable, 14-pin w/Ferrite
4 A-20028
WPC '95 Power Driver PCB
13 5795-10938-15 Ribbon Cable, 26-pin, 15"
5 A-20516-50047
WPC '95 Audio Visual PCB
6 A-20119-50047
WPC '95 CPU PCB
Miscellaneous Parts
7 04-1 0450-50047 Backbox, Wood
8 A-20866
Speaker/Display Assembly
08-7456
Backbox Glass: 27 x 18-7/8"
a) 5555-12924-00
Speaker Tweeter, 15w, 40
20-9718
Wing Screw, 3/8-16 x 2"
b) 5555-12856-00
Speaker, 5-1/4", 25w, 40
31-1357-50047 Screened Translight
c) 5045-12914-00
Capacitor, 10IJfd., 50v (±20%)
d) 5901-12784-00
Dot Matrix Display/Driver Board
9 A-13379
Lock & Plate Assembly
Backbox Cables
H-20479
Dot Matrix Display Power Cable
H-20477
Logic Power Cable
H-20478
Secondary Cable
H-20858.1
Insert Cable
