Power Driver Board Continued ..•
J125-1 Red-Brown, lamp row 1 to playfield
J125-2 Red-Black, lamp row 2 to playfield
J125-3 Key
J125-4 Red-Orange, lamp row 3 to playfield
J125-5 Red-Yellow, lamp row 4 to playfield
J125-6 Red-Green, lamp row 5 to playfield
J125-7 Red-Blue, lamp row 6 to playfielet
J125-8 Red-Violet, lamp row 7 to playfield
J125-9 Red-Gray, lamp row 8 to playfield
J126-1
N/C
J126-2 N/C
J126-3 Key
J126-4
N/C
J126-5
N/C
J126-6
N/C
J126-7 Red-Blue, lamp row 6 to cabinet
J126-8 Red-Violet, lamp row 7 to cabinet
J126-9 Red-Gray, lamp row 8 to cabinet
J127-1 White-Green, 9.8Vac from xformer secondary
J127-2 White-Green, 9.8Vac loop from J112-1
J127-3 White-Green, 9.8Vac from xformer secondary
J127-4 Keys
J127-5 White-Green, 9.8VAC loop from J112-3
J128-1 White-Red, 16Vac loop from J102-2
J128-2 White-Red, 16Vac from xformer secondary
J128-3 White-Red, 16Vac loop from J102-4
J128-4 White-Red, 16Vac from dormer secondary
J128-5 Black-Yellow, 16Vac loop from J102-6
J128-6 Black-Yellow, 16Vac from xformer secondary
J12B-7 Key
J12B-B Black-Yellow, 16Vac loop from J102-9
J128-9 Black-Yellow, 16Vac from xformer secondary
J129-1 Red, 9Vac from xformer secondary
J129-2 Red, 9Vac from transformer secondary
J129-3 Key
J129-4 Blue-White, 13Vac from xformer secondary
J129-5 Blue-White, 13Vac loop from J101-4
J129-6 Blue-White, 13Vac from xformer secondary
J129-7 Blue-White, 13Vac loop from J101-6
J130-Not Used
J131-Not Used
J132-Not Used
J133-1 Red-Orange, +50V to coils
J133-2 Red-Brown, +50V to coils
J133-3 Red-Black, +50V to coils
J133-4 Key
J133-5
N/C
J133-6 Red-White, +20V to playfield flasher
J134-1
N/C
J134-2
N/C
J134-3
N/C
J135-4 Key
J134-5 Red-White, +20V to insert panel flasher
J135- Not Used
J136- Not Used
J137- Not Used
J138- Not Used
J139-1 Key
J139-2 Gray-Yellow, +12V to playfield boards
J139-3 Black, ground to playfield boards
J139-4
N/C
J139-5 Black-White, signal for coin meter to Coin Door
Interface board J2-7.
J140-Not Used
J141-1 Key
J141-2 Gray-Yellow, +12V to Coin Door Board J2-2
J141-3 Black, ground to Coin Door Board J2-1
J141-4
N/C
< -~
((
..
