Power Driver Board Continued ...
J108-1 Blue-Brown, solenoid 25 drive to insert panel
flasher
J 108-2 Blue-Red, solenoid 26 drive to insert panel
flasher
J108-3 Blue-Orange, solenoid 27 drive to insert panel
flasher
J108-4 Key
J108-5
N/C
J 109-1 Blue-Brown, solenoid 25 drive to playfield
flasher
J109-2 Blue-Red, solenoid 26 drive to playfield flasher
J109-3 Blue-Orange, solenoid 27 drive to playfield
flasher
J109-4 Blue-Yellow, solenoid 28 drive to playfield
flasher
J109-5
N/C
J109-6
N/C
J109-7 Key
J109-8
N/C
J109-9
N/C
J110- Not Used
J111-1 Black-Brown, solenoid 17 drive to playfield
flasher
J 111-2 Black-Red, solenoid 18 drive to playfield flasher
J111-3 Black-Orange, solenoid 19 drive to playfield
flasher
J 111-4 Black-Yellow, solenoid 20 drive to playfield
flasher
J111-5 Blue-Green, solenoid 21 drive to playfield coil
J111-6 Blue-Black, solenoid 22 drive to playfield
flasher
J
111-7 Blue-Violet, solenoid 23 drive to playfield
flasher
J111-8 Blue-Gray, solenoid 24 drive to playfield flasher
J111-9 Key
J111-10
N/C
J111-11
N/C
J 111-12 Red-Orange, tieback diode for solenoid 21
J111-13
N/C
J112-Not Used
J113-1 Brown-Black, solenoid 9 drive to playfield coil
J113-2 Key
J 113-3 Brown-Red, solenoid 10 drive to playfield coil
J 113-4 Brown-Orange, solenoid 11 drive to playfield
coil
J113-5 Brown-Yellow, solenoid 12 drive to playfield coil
J113-6 Brown-Green, solenoid 13 drive to playfield coil
J 113-7 Brown-Blue, solenoid 14 drive to playfield coil
J 113-8 Brown-Violet, solenoid 15 drive to playfield coil
J113-9 Brown-Gray, solenoid 16 drive to playfield
flasher
J114-1
N/C
J114-2
N/C
J114-3
N/C
J114-4 Key
J 114-5 Brown-Gray, solenoid 16 drive to insert panel
flasher
J115- Not Used
J116-1 Violet-Brown, solenoid 1 drive to playfield coil
J116-2 Violet-Red, solenoid 2 drive to playfield coil
J116-3 Key
J 116-4 Violet-Orange, solenoid 3 drive to playfield coil
J116-5 Violet-Yellow, solenoid 4 drive to playfield coil
J116-6 Violet-Green, solenoid 5 drive to playfield coil
J116-7 Violet-Blue, solenoid 6 drive to playfield coil
J116-8 Violet-Black, solenoid 7 drive to backbox coil
J116-9 Violet-Gray, solenoid 8 drive to playfield coil
J117- Not Used
J118- Not Used
J 119-1 Red-Green, +50V to lower right flipper coil
J119-2 Red-Green, loop from J119-1
J119-3 Key
J 119-4 Red-Blue, loop from J 119-5
J 119-5 Red-Blue, +50V to lower left flipper coil
J 119-6 Red-Violet, +50V to solenoids 33 and 34
J119-7 Red-Violet, loop from J119-6
J 119-8 Red-Gray, +50V to solenoids 35 and 36
J 119-9 Red-Gray, Loop from J 119-8
J120-1 Orange-Gray, solenoid 36 drive to coil
J120-2
N/C
J120-3 Yellow-Gray, solenoid 35 drive to coil
J120-4 Orange-Violet, solenoid 34 drive to coil
J120-5
N/C
J120-6 Yellow-Violet, solenoid 33 drive to coil
J120-7 Orange-Blue, holding, lower left flipper coil
J120-8
N/C
J120-9 Yellow-Blue, power, lower left flipper coil
J120-10 Key
J 120-11 Orange-Green, holding, lower right flipper coil
J120-12
N/C
J120-13 Yellow-Green, power, lower right flipper coil
J121-Not Used
J122-1 Key
J122-2
N/C
J122-3 Yellow-Gray, lamp column 8 to cabinet
J123-1 Yellow-Brown, lamp column 1 to playfield
J123-2 Yellow-Red, lamp column 2 to playfield
J123-3 Yellow-Orange, lamp column 3 to playfield
J123-4 Yellow-Black, lamp column 4 to playfield
J123-5 Yellow-Green, lamp column 5 to playfield
J123-6 Yellow-Blue, lamp column 6 to playfield
J123-7 Yellow-Violet, lamp column 7 to playfield
J123-8 Key
J123-9 Yellow-Gray, lamp column 8 to playfield
J 124-Not Used
3-27
