A-20636
Spinning Lamp Unit Assembly
Item Part Number
Description
Item Part Number
Description
1
01-14156
Spinning Lamp Assembly
15
20-8712-18
"E" Retaining Ring
2
01-14157
Spin Lamp Act. Switch
16
4700-00021-00 FW, 13/64 X 7/6 X 22ga.
3
SW-1A-206
Spinning Lamp Switch Assy.
17
4700-00072-00 FW, 17/64 x 35/64 x 22ga.
4
03-8347
Gland
18
20-8712-25
"E" Reatining Ring
5
03-8363-1
Locking Nut
19
4004-01003-04 Mach. Screw, #4-40 x 1/4"
6
04-10412
Adj. Screw Assembly
20
4008-01003-05 Mach. Screw, #8-32 x 5/16"
7
H-20863
Cable
21
4108-01013-08 Sh. Metal Screw, #8 x 1/2"
8
04-10308
Shaft/Bracket Assembly
22
4410-01132-01 Nut #10-32 ESN
9
A-17826
Socket & Bulb Assembly
23
4005-01003-12 Mach. Screw, #5-40 x 3/4"
10
03-9466
Spinning Lamp Disk
24
01-3670-1
Switch Plate
11
02-5233
Post - Spinning Lamp
12
03-7301
Rotate Bumper Insulator
Associated Assembly:
13
23-6770
Bumper
14
03-9465
Actuator - Spin Lamp Switch
25
31-2526
Lamp
2-23
