RELAY SW.
I
WIRE
COLORS
B-7
DIAG.
TYPE
LOC.
SWITCH OPERATION
22C B-W
RELAY
-w-
2-D
22D
-J-
Y-G
Y-B
22B
-J.•
-J-
22A
-J-
-J-
E-l.6 M&:B OPENS TO COIL ON THIS RELAY AND CLOSES
TO 50 POINT RELAY. (WHEN BALL HITS 2-D
TARGET SW.).
A-8 N.O. TO 2-D TARGET-LITE.
D-20 N.O. IN SERIES WITH SWITCH 24B ON 3-D RELAY.
D-20 N.O. IN SERIES WITH SWITCH 24A ON 3-D RELAY.
I
3-D
RELAY
23D -J-
-J-
23C -J-
-J-
23B
-J-
-J-
23A -W-
B-Y
24c
-.J-
Y-O
Y-B
24B -J-
-J-
24A
-J-
-3-
E-20 N.O. IN SERIES WITH SWITCH 25A ON REPLAY
CONTROL RELAY.
D-19 N.O. IN CIRCUIT TO DOUBLE BONUS RELAY. (SEE
SWITCH 19C ON I-D RELAY.
E-20 N.O. IN SERIES WITH SWITCH 30B ON TRIPLE
BONUS RELAY.
A-7 N.O. TO 3-D TARGET LITE. ALSO IN SERIES
WITH 21A ON ~D RELAY.
E-16 M&:B OPENS TO COIL ON THIS RELAY AND CLOSES
TO 50 POINT RELAY. (WHEN BALL HITS 3-D
TARGET SW.).
E-20 N.O. IN SERIES WITH SWITCH"30B ON TRIPLE BO-
NUS RELAY.
E-20 N.O. IN SERIES WITH SWITCH 30B ON TRIPLE
BONUS RELAY.
~EPLAY 25B
N.C. IN SERIES WITH SWITCH 18A ON 3-C RELAY.
CONTROL
25A B-R
RELAY
-3-
-J-
B-R
DOUBLE ~7B R-B
BLU-R
BONUS
R-BLU
RELAY 27A O-R
-J-
28B
-0-
O-B
E-20 N.C. TO SPECIAL RELAY COIL. CIRCUIT ORIG-
INATES AT SWITCH ID ON I-A RELAY.
D-12 M&B IN CIRCUIT TO BONUS UNIT RESET COIL.
B-8 N.O. TO "DOUBLE BONUS" LITE, THRU SW. ON
TRIPLE BONUS RELAY.
D-19 M&B IN CIRCUIT TO 1,000 POINT RELAY (WHEN
COLLECTING BONUS).
