RELAY
SW.
WIRE OIAG. TYPE
SWITCH OPERATION
COLORS
LaC.
18D
-J-
E-16
M&B
OPENS TO COIL ON THIS RELAY AND CLOSES
Y-R
TO 100 POINT RELAY. (WHEN BALL HITS
3-C
W-R
3-C TARGET SW.).
18c O-G
A-7 N.O TO J-C TARGET·LITE~
RELAY
-w-
18B -J-
C-20 N.O IN SERIES WITH SWITCH 2B ON 1-A RELAY
-J-
AND 20A ON 1-D RELAY.
18A -J-
B-7 N.O IN SERIES WITH SWITCH 16A ON 2-C RELAY.
-J-
19D -J-
E-20 N.O IN SERIES WITH SWITCH 21D ON 2-D RELAY.~
1-D
-J~
19C
-J-
C-19 N.O IN SERIES WITH SWITCH'
210
ON 2-D RELAY.
-Y-
RELAY
19B -J-
0-20 N.O IN SERIES WITH SWITCH 21B-ON 2-D RELAY.
-J-
19A -J-
B-7 N.O TO "0" STAR LITE. ALSO IN SERIES WITH
B-R
SWITCH 25B ON REPLAY CONTROL RELAY.
200
-J-
E-16 M&B OPENS TO COIL ON THIS RELAY AND CLOSES
Y-BLU
TO 50 POINT RELAY. (WHEN BALL HITS 1-0
Y-B
TARGET SW.).
20C B-BLU
A-8 N.O TO 1-0 TARGET LITE.
-w-
20B -J-
D-20 N.O IN SERIES WITH SWITCH 22B ON 2-0 RELAY •
-J-
20A -J-
0-20 N.D IN SERIES WITH SWITCH 22A ON 2-D RELAY.
-J-
210
-J-
2-D
-J-
E-20 N.O IN SERIES WITH SWITCH 230 ON 3-D RELAY.
21C -J-
D-19 N.O IN SERIES WITH SWITCH 23C ON 3-D RELAY.
-J-
RELAY
21B-
-J~
D-20 N.O IN SERIES WITH SWITCH 23B ON 3-D RELAY.
-J-
21A -J-
A-7 N.O IN SERIES WITH S·WITCH 19A ON 1-D RELAY.
B-Y
