IMPORTANT!
Playfield pitch angle
can
affect the operation of the plumb bob tilt. The plumb bob weight is among the
parts in the cash box. After completion of the desired playfield pitch angle setting, the operator should
install the weight and adjust this tilt mechanism for proper operation. The unit is factory installed for
a
6-
112degree angle. If
an
adjustment is necessary, loosen the screw at the bottom of the unit. Move the
pointer, one groove at
a
time to the left or the right, depending on the degree desired. Hold the pointer in
place and tighten screw.
POWER UP
20. If a padlock is desired, install the security bar as shown below in Figure 16.
Hasp Hinge Bracket
01-14085.1
Hasp Staple Bracket
01-14086.1
FIGURE 16
'&CAUTION
After assembly and installation at its site location, this game must be plugged Into a properly
grounded outlet to prevent shock hazard, and to assure proper game operation. DO NOT use a
'cheat.'
plug to defeat the ground pin. DONOT cut off the ground pin.
21. With the coin door closed, plug the game into a properly grounded outlet and switch it on. In normal
operation the game performs Start-up Tests. Once the Start-up tests have been successfully
completed, the game enters the Attract mode.
22. IMPORTANT: Fill out and return the registration card.
1-8
